Help CenterCable tv Headend sd Low Bit Rate Mpeg and H.264 Encoder With Multiplex COL5111AX
Related Products
-
COL5141A 4 in 1 MPEG-2 Encoder/mpeg-2 Encoder Multiplexer 4 in 1/catv Digital Headend Satellite Digital tv EncoderNegotiableMOQ: 1 Piece -
COL5141B Mpeg4 Mpeg2 Strong Encoder 4in 1 Multiplexer/Encoder 4 in 1/MPEG-2 Super Encoder (4 in 1)NegotiableMOQ: 1 Piece
-
COL5141C Mpeg4 H264 sd Video Encoder Multiplexer/Encoder SD/H.264 Encoder 4 in 1NegotiableMOQ: 1 Piece
-
COL5100F H264 Mpeg-2 Mpeg-4 Hdmi to ip hd Flash EncoderNegotiableMOQ: 1 Piece
-
COL5111AX MPEG-2 H.264 SD Video Encoder, MultiplexerNegotiableMOQ: 1 Piece
Specifications
1. Support H.264,MPEG2 Encoding2. 4 Mono encoding
3. 1SPTS UDP IP Output
4. MPEG1 Audio Layer 2,LC-AAC,HE-AAC v2
Outline
The COL5111AX MPEG-2 H.264 SD Encoder is our newest professional SD audio & video
encoding and multiplexing device with powerful functionality. It has 1 video with two different
audios encoding in the same time, supporting MPEG-2 and H.264 encoder type. Furthermore,
it can support the MPEG-1 Audio layer 2, LC-ACC, HE-AAC, and can support ultra low bit-rate
(0.25~15Mbps for H.264 encoding, and 0.5~15Mbps for MPEG-2 encoding). Moreover, it has
an ASI input and can multiplex the encoder channel and ASI/IP output in the same time.
Features
- Support H.264,MPEG2 Encoding
- Support 4 Mono encoding
- Support ultra low bit rate encoding
- Applicable for one Seg/ISDB-T utilization
- MPEG1 Audio Layer 2,LC-AAC,HE-AAC v2
- Support 1SPTS UDP IP Output
- Support VBR/CBR video encoding
- Real-time output bit-rate monitoring
- supports LCD/ Keyboard operation
- supports NMS
Specifications
Input |
1×CVBS input , 1xSD-SDI input ( support Closed Caption) |
||
2x RCA inputs, 1x XLR inputs | |||
1×ASI input, BNC interface | |||
Video |
Resolution |
PAL:720*576/352*288/320*240/320*180/176*144/ 160*120/160*90-50Hz |
|
|
NTSC:720*480/352*288/320*240/320*180/176*144/ 160*120/160*90-59.94Hz | |||
Encoding |
MPEG-2 /H.264 |
||
Bit-rate |
0.25~15Mbps for H.264 encoding 0.5~15Mbps for MPEG-2 encoding |
||
Bit-rate control |
CBR/VBR |
||
GOP Type |
IBBP |
||
Advanced Pretreatment |
De-interlacing, noise reduction, sharpening |
||
Audio |
Encoding |
MPEG1 Audio Layer 2,LC-AAC,HE-AAC |
|
Sample Frequency |
48KHz |
||
Sample accuracy |
24 bit |
||
Bit-rate |
64Kb/s~384Kb/s (each channel) |
||
Multiplexing |
1 ASI input multiplexed with local 1 channels TS |
||
Stream |
2 × ASI outputs, BNC interface MPTS over UDP,10/100Base-T Ethernet interface (UDP unicast / multicast), LCD/keyboard operating, NMS support, Chinese-English control interface |
||
Ethernet software upgrade | |||
General |
Dimension |
482mm×455mm×44.5mm |
|
Weight |
4kg |
||
Temperature |
0~45°C(Working),-20~80°C(Storage) |
||
Power Supply |
AC 110V±10%,50/60Hz or AC 240V±10%,50/60Hz |
||
Power Consumption |
17.6W |
||
Send Inquiry to This Supplier
