8ch encoder, mpeg2 ip encoder, super encoder support mpts spts multicast unicast

Features

Description

Video

Channel:                              8 channels

Inputs:                                 Analog composite (NTSC/PAL)

Connector:                          BNC (75)

Audio

Channel:                              16 channels

Inputs:                                 Analog

No. of Channels:                 R/L

Sample Rate:                      32/ 44.1/ 48KHz

ASI Input

Bit Rate:                              270Mbit/s ± 100 ppm

TS Packet Length:              204, 188 bytes adaptive

Programs:                            1~24 programs

Connector:                           BNC (75)

Return Loss:                        ≥15dB, 27 to 270MHz

Video Encoding

Video Format:                     MPEG-2 (MP@ML)

Frame arrangement:          IPB, IP, IBI, I

Movement Predict:             Auto frame, scene predict

DC precision:                      8~11bits

Bit Rates:                             1.5 to 15 Mb/s (4:2:0)

H Resolutions:                     720, 704, 640, 544, 528, 480

                                              and 352

V Resolutions:                     576 and 480

Audio Encoding

Audio Format:                    MPEG-1 Layer-1/ Layer-2

Bit Rates:                            32Kbps, 64Kbps, 128Kbps,

                                             192Kbps, 256Kbps, 384Kbps

DVB ASI Output

Connector:                          BNC(75)

TS rate:                               0~216Mbps

TS packet:                          188 bytes

Output Level:                     800mVpp nominal

Return Loss:                       ≥15dB, 27 to 270MHz
