Home > Manufacturing & Processing Machinery > Machine Tools > Punching Machine > Can Cover End Bottom Tin Press Machine
Can Cover End Bottom Tin Press Machine
Negotiable
MOQ: 1000 Dozens (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Power Source:
Pneumatic
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Can End Tin Can Press MachineNegotiableMOQ: 1000 Dozens -
the Mould of Tin Can Making EquipmentNegotiableMOQ: 1 Set
-
Automatic Round Tin Can Cover Lining Compound MachineUS$ 3,200 - 4,200MOQ: 1 Set
-
Semiautomatic Metal Can Lid Making MachineNegotiableMOQ: 1000 Dozens
-
Can Bottom Lid Press MachineNegotiableMOQ: 1000 Dozens
Condition
New
CNC or Not
Normal
Power Source
Pneumatic
Place of Origin
Jiangsu, China
Brand Name
Yangli
Model Number
J23-16
Voltage
380V
Weight
600kg
Dimension(L*W*H)
915x700x1690mm
Warranty
1 year, 1 year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Can Cover End Bottom Tin Press Machine1, good in can making
2, good price
2,deilevey in time
Product Description
<
| Model Specification | J23-16 | J23-40 | J23-63 | ||||
| Nominal forece | KN | 160 | 400 | 630 | |||
| Stroke under nominal force | Mm | 2 | 4 | 4 | |||
| Slide block stroke | Mm | 0-70 | 20-120 | 20-120 | |||
| Number of stroke | min | 125 | 55 | 50 | |||
| Max die set height | Mm | 170 | 220 | 260 | |||
| Die set height adjustment | Mm | 30 | 70 | 80 | |||
| Distance from slide block centre to the frame | Mm | 170 | 260 | 260 | |||
| Worktable dimensions(F*B×L*R) | Mm | 320 | 480 | 480 | |||
| 480 | 710 | 710 | |||||
| Dimensions of worktable hole | Mm | φ100 | φ220 25 φ180 |
φ200 45 φ180 |
|||
| Thickness of boiister | Mm | 60 | 80 | 90 | |||
| Hole dimensions in bed(diameter×F*B×L*R) | Mm | φ210 | φ200 | φ250 | |||
| 160 | 150 | 200 | |||||
| 240 | 300 | 340 | |||||
| Dimensions of side block botton surface(F*B×L*R) | Mm | 180 | 270 | 280 | |||
| 200 | 320 | 320 | |||||
| Size of the handle hole(diameter×depth) | Mm | φ40 | φ50 | φ50 | |||
| 60 | 70 | 80 | |||||
| Max.tilting angle of body | ° | 25 | 25 | 25 | |||
| Distance between columns od body | Mm | 220 | 300 | 350 | |||
| Motor Power | Kw | 1.5 | 4 | 5.5 | |||
| Outline dimension(F*B×L*R×H) | Mm | 1150 | 1600 | 1810 | |||
| 900 | 1180 | 1350 | |||||
| 1910 | 2310 | 2640 | |||||
| Net/Gross weight | Kg | 1080 | 3180 | 3800 | |||
| 1405 | 3600 | 4218 | |||||
Machine pictures:
Some accessories of can :
Lid,Bottom,Sealing ring,metal hoop,metal handle,plastic handle
Sample cans we can make: chemical/oil/paint/adhensive/gasoilne/garbage cans/tank/bustek/barrels
Customers from all over the world: the main market is in Asia,south and north America, Africa.
Customers training in our factory
