Help CenterNew Design Hot Automatic Can Body Making Machine
Related Products
-
High Quality Automatic Round Can Welding MachineUS$ 50,000 - 51,500MOQ: 1 Set -
FN2000-C/Welding Machine for Making Tin CansUS$ 13,500 - 14,000MOQ: 1 Set
-
Automatic Square Can Making Equipments for Different SizeUS$ 41,000 - 45,000MOQ: 1 Set
-
Post-feeding Welding Machine for Can Body/side Seam WeldersUS$ 19,000 - 20,000MOQ: 1 Set
-
Tin Can Body Maker MachineUS$ 45,000 - 50,000MOQ: 1 Set
Supply Automatic Oil Can Seam Welding Machine
FBZ-A/FBZ-B:
FBZ-C:
Production details:
Model |
FBZA |
FBZ-B |
FBZ-C |
Place of origin |
Jiangsu China |
Jiangsu China |
Jiangsu China |
Brand |
Suzhou FIRST |
Suzhou First |
Suzhou First |
Power |
3N380V/50Hz 25KVA |
3N380V/50Hz 25KVA |
3N380V/50Hz 25KVA |
Welding Speed |
6—18m/min |
6—18m/min |
6-24m/min |
Capacity |
≤30 cpm |
≤60cpm |
≤150cpm |
Diameter range |
ø250-ø290 mm |
ø120-ø180mm |
ø52-ø180mm |
Height range |
180-450 mm |
≤ 250mm |
≤ 300mm |
Overlap |
0.8—1.2 mm |
0.6-0.9mm |
0.4-0.6mm |
Thickness |
0.28—0.4mm |
0.18-0.4mm |
0.16-0.3mm |
Copper wire |
ø1.5 T2 |
ø1.5 T2 |
ø1.5T2 |
Compressed air |
900L/min 0.5Mpa |
900L/min 0.5Mpa |
900L/min 0.5Mpa |
Cooling water |
≥0.3MPa8~10L/min |
≥0.3MPa8~10L/min |
≥0.3MPa8~10L/min |
Weight |
2000kg |
2000kg |
1850kg |
Overall dimensions |
2100×1900×1900mm |
2100x1900x1900mm |
2000x1800x1600mm |
Advatages:
· It is a complete automatic small metal cans welding equipment,which consists of can round forming
welding in a machine adopt the servo control system.
· Using the Japanese's Mitsubishi PLC control host, Panasonic servo power drive, touch screen
human-machine interface operation.
· The scheme of tension control project makes the tension on the wire coordinate , reduce the influence
of jitter of the welding wire tension.
· The welder current is adopted the new digital circuit micro control system, which make the machine
with the function of rising slowing and descending slowly for front & back end current.
· System a high degree of automation, only set up the basic tank model parameters and the running
speed, running other data system automatically generated.
· Equipment running status monitoring, fault automatic alarm and providing processing solutions.
· New type conveying device of can body, simple and easy size change-over process
Sample cans we can make: chemical/paint drum/barrels/cans, oil barrels/cans, grease oil cans, food cans, adhesive cans, garbage basket, gasoline cans, spray cans, ink tank, etc.
Customers from all over the world: the main market is in Asia,south and north America ,Africa.
