BZJ5038B SEMI-AUTO SLEEVE WRAPPER & BSE-5040A shrink TUNNEL

Specifications

semi automatic sleeve wrapper
GMP standard
material: PE, PP, OPP etc
CE
ISO9001

BZJ5038B  SEMI-AUTO SLEEVE WRAPPER & BSE-5040A shrink TUNNEL





Summary:



BZJ5038B semi-auto sleeve wrapper is suitable for wrapping pop-cans, bottles, etc, with bottom-tray or without bottom-tray, working with BSE-5040A jet PE-film shrink tunnel or other PE shrink tunnel BSE-5038. Enlarge packing range or custom-made machine according to customer’s requirement.







Characteristic:



1. Upper and down electromagnetic switch prevent sealing mistakes, and protect operator.

2. Every simply and easy to adjust machine to match different packing size.

3. Simple operation and maintenance with high packing efficiency.

4. ‘Schneider’ AC contractor, and Intelligent temperature controller performs stable.

5. Automatic alarm security system protects machine and operator.

6. Large power conveyer motor, with stepless speed regulating, ensures smooth feeding.

7. Two large power fans make the temperature of shrink tunnel every even and stable, this ensures the excellent effect of shrinking in one time.

8. Super cooling system cools the packing and makes the figuration perfectly.



   Specification:



Model	BZJ-5038B(Pneumatic)
Power supply	220-240V, 50-60Hz;1.8KW
Capacity	0-6 packs/min
Sealing time/shrink time	0.5-1.5s, 0-0.6s
Conveyor loading	30kg
Film thickness	0.03-0.25mm
Max. packing dimension(L*W*H)	450 x 270 x 350mm
Min. packing dimension(L*W*H)	250 x 60 x 60mm
Machine size(L*W*H)	1020 x 830 x 1980mm
Weight	225kgs
