Help Center30000RMP Professional Nail Drill Original Made in Korea Manicure Nail Drill & Dental Polishing Machine
Related Products
-
30000RMP Professional Nail Drill Original Made in Korea Manicure Nail Drill & Dental Polishing MachineUS$ 89 - 115MOQ: 8 Pieces -
Nail Drill Pen Nail Drill Replaced Part Manicure Filing HandpieceUS$ 13.99 - 19.99MOQ: 10 Pieces
-
700 Newest Electric Nail Drill Manicure Glazing MachineUS$ 22.99 - 33.99MOQ: 10 Pieces
-
400 Newest Electric Nail Drill Manicure Glazing MachineUS$ 20.99 - 33.99MOQ: 10 Pieces
-
4500 Newest Electric Nail Drill Manicure Glazing MachineUS$ 23.99 - 37.99MOQ: 10 Pieces
Features:
1,Easy to use dialing speed control,
2,Forward and reverse operation swith,
3,0-30000RPM,
4, Extremely quiet and smooth - No Vibration,
5,Fashion design for comfrt grip,
6,Nail machine stand inclued,
7,Foot pedal for easy operation .
8, DC out A&B work at the same time
Specification:
Main (power supply & Control) part: M-3 Champion
Rated voltage range:110-250V 50/60Hz
Output rated voltage :DC12V,0.5A
Weight: 882g
Dimension: 117(W)X154(D)X72(H)mm
Color: White, pink, blue
Direction: Forward&Reverse
Hand piece(motor)part: SDE-SH20N(30V)
Motor Type: Carbon Brush Micromotor
Input voltage:DC30V
No load speed:0-30000RPM
Torque: 2.7Ncm
Weight: 146g
Dimenstion: 128(L)mmX26(D)mm
Motor Cable Length: 1.5m
Package contains:
Enginery,Twist-lock handpiece ,holder ,a set of bits
Foot Pedal: SFP-27(on-off)
SFP-73(Variable Speed Control)
Handpiece: Rubber Handpiece Stand
Out package: 8pcs/ctn
The Manicure nail drill & Dental polishing machine
Operation Manual
Thanks for purchasing the Manicure nail drill & Dental polishing machine produced by our company. To ensure smooth operation and safe performance to use this Manicure nail drill & Dental polishing machine,pls.read the manual of this Manicure nail drill & Dental polishing machine carefully before use the Manicure nail drill & Dental polishing machine :
A. Installation and wire connection the Manicure nail drill & Dental polishing machine :
1,Connect the 5-pin plug of the Manicure nail drill & Dental polishing machine portable grinding head /hand piece to the OUTPUT socket at the main panel .
2,Connect the Manicure nail drill & Dental polishing machine pedal switch to the FOOT S/W socket.
3,Select grinding mould of different sizes according to actual requirements, and fasten it into the front of the portable grinding head of the Manicure nail drill & Dental polishing machine .
4,Switch the speed control of the Manicure nail drill & Dental polishing machine to the left.
5,Connect with the main source power for the Manicure nail drill & Dental polishing machine .
B. Manicure nail drill & Dental polishing machine operation :
1,Press the Manicure nail drill & Dental polishing machine funtion switch on the right to HAND for manual control ,the indicator of the Manicure nail drill & Dental polishing machine will be on.
2,Turn the Manicure nail drill & Dental polishing machine SPEED CONTROL to the right to accelerate the grinding head.
3,When the funtion switch of Manicure nail drill & Dental polishing machine is pressed to FOOT,step on the pedal the speed will be acceleerated,and loose the foot,the speed will decrease(foot switch is optional)
4,The turning directions of this Manicure nail drill & Dental polishing machine can be swapped: FWD means chockwise direction and REV means counterclosckwise direction.
5,Adjust the speed of the Manicure nail drill & Dental polishing machine grinding head within a resonable range.
C.Instructions of this Manicure nail drill & Dental polishing machine :
1,Don’t change the turning directions of this Manicure nail drill & Dental polishing machine too frequently,otherwise it will damage the grinding head of Manicure nail drill & Dental polishing machine .
2,Turn the Manicure nail drill & Dental polishing machine SPEED CONTROL counterclockwise to decelerate the grinding head to the minimum before turning off and switch the main power source to O .
3,After the Manicure nail drill & Dental polishing machine operation,put the grinding head on the top of the main panel.
4,While the grinding head of the Manicure nail drill & Dental polishing machine is in operation,never pull out the 5-pin plug of the portable grinding head.
5,For long idle time of the Manicure nail drill & Dental polishing machine ,pls.disconnect the source power.
6,Any unauthorized disassembling of the Manicure nail drill & Dental polishing machine is prohibited. In case of any breakdown for the Manicure nail drill & Dental polishing machine ,ntact the agent or authorized repair center. We promise swift, high-quality and satisfactory service.
