Fan and Water Pump Type Frequency Converter 45KW

Fan and Water Pump Type Frequency Converter 45KW thumbnail-1
Fan and Water Pump Type Frequency Converter 45KW photo-1
US$ 1,210 - 1,282.6 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
FULL
Model Number:
FU9000E3450V3T
Contact Supplier Request Quote Chat Now
Zhejiang Fullwill Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name FULL
Model Number FU9000E3450V3T
Output Power Other, 45kw
Output Type Triple
Size 650x370x275mm
Weight 50kgs
Input Voltage 380V
Output Voltage 380V
Type Other, AC inverter
Output Frequency 0-400HZ
Output Current 91A

Specifications

Frequency inverter E series is in accordance with the requirement of electromagnetic compatibility IEC61800.

Frequency converter(frequency inverter,variable frequency drive)



1.Application



This type is economic,high-efficiency,stable,adopting special 32-bit micro-

processor, and it is controlled by electric motor with high-precision frequency outputing ,

wide range of voltage fluctuation,low exotherm of inner element,prolonging the life

of operation of product,owning complete protection and fault diagnosis system

and the performance index surpassing the same products in the world.However,the price

 is only 50% of them.



2.Usage



FU9000 series is designed according to the complicated driving technics to satisfy so

many manufacturing fields:



1)Fan, water pump, compressor

2)Weave and chemical fibre machine

3)Injection machine

4)Petrochemical industry, metallurgy industry,cement machinery,machanism, belt

   transport industry

5)Drilling and piling machine

6)Food and carpentry machine



3.Specification



Item

FU9000-E series

Control Method

SPWM

Input Power Supply

400V Power Supply: 340VAC~460VAC

220V Power Supply: 180VAC~250VAC



Frequency Control

Frequency Range

0.1~400.00Hz

Frequency Accuracy

Digital:0.01%(-10~40°C)

Analog:0.1%(25±10°C)

Frequency Setting Resolution

Digital:0.01Hz

Analog:1% of Max Operating Frequency

Output Resolution

0.01Hz

Operator Setting Method

Press← or ∧ or  ∨ to set

Analog Setting Method

0-5V /0-10V

4-20 mA /0-20mA

Other functions

Frequency up/lower limit,start frequency,stopping frequency,three skip frequencies can be individually set

General Control

Acceleration/Deceleration time

0.1-6500s four selectable combinations of independent acceleration and deceleration setting.

V/F Curve

Set V/F curve at will

Torque Control

Max Torque 10.0% Max output voltage,the starting torque can reach 150% at 1.0Hz

Multi-function input terminals

6 multifunction input terminals for 8 multi-speed,easy PLC,4 Accel/Decel time,UP/DOWN command,external emergency stop

ITEM

HCI-A

Communication control

RS485

Operating temperature

-10~40°C

Humidity

0~95% relative humidity

Vibration

0.5G or lower

Protection Function

Instantaneous over current

Approx.200% 1 minute

Over load

Inverter:150% 1 minute

Motor Overload protection

Electronic thermal overload relay

Over voltage

23 series:DC bus over 400 Vdc

43 series:DC bus over 800Vdc

Under voltage

23 series:DC bus voltage drop 200Vdc

43 series:DC bus voltage drop 400Vdc



Momentary power loss

0~2 seconds:The inverter can be restarted by speed search.

Heat sink over heat

Protected by thermistor



Multi-function output termianls

5 multifunction output terminals for the displaying and warning of on-running,zero speed,counting and external fault information.



Other functions

AVR,Decelerating stop or free-stop,DC brake,auto restart tracking,easy PLC auto energy saving,adjustable carrier Frequency(Max 20KHz)

Digital operator monitor

Frequency command,output frequency,speed output current,output voltage,DC bus voltage and rotation direction.



Fan and water pump type frequency converter 45KWFan and water pump type frequency converter 45KW
