Free Standing Potato Chips Manufacturing Plant Potato Chips Flavour

Free Standing Potato Chips Manufacturing Plant Potato Chips Flavour photo-1
Free Standing Potato Chips Manufacturing Plant Potato Chips Flavour photo-2
Free Standing Potato Chips Manufacturing Plant Potato Chips Flavour photo-3
Free Standing Potato Chips Manufacturing Plant Potato Chips Flavour photo-4
Free Standing Potato Chips Manufacturing Plant Potato Chips Flavour photo-5
Free Standing Potato Chips Manufacturing Plant Potato Chips Flavour photo-6
US$ 5,000 - 95,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Honest
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shandong, China
Brand Name Honest
Model Number HFC800
Type Dryer
Voltage 380V/50HZ
Power(W) 40KW
Weight 1200kg
Dimension(L*W*H) 5000x1000x1600mm
Certification CE ISO
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas
Products Description

Free Standing Potato Chips Manufacturing Plant Potato Chips Flavour




Machine Details

1. Potato Washing & Peeling Machine

Features

1. Rollers are made of nylon rope, a light material which is very durable.

2. Separated dirt and sediment can be
removed with the circulation of water.

Technical Data

Specification
Power
Capacity
Weight
Dimensions
HPM10
0.75KW/220V
80-100Kg/h
60Kg
690x430x860mm
HPM30
1.1KW/380V
180-200 Kg/h
80Kg
710x630x840mm

2. Potato Chips Slicing Cutting Machine

Features

1. Suitable for cutting potato, sweet potato, cassavas,

carrot, radish etc.

2. Cut vegetables into slices, strips and chips.
3. Thickness of potato chips & slices are adjustable.

Application

1.Application in potato chips and French fries production

making.

2. Helpful cutting device in large labor and restaurant.
3. Suitable cutting machine in root vegetable processing.

Technical Data

Specification
Power
Capacity
Weight
Dimensions
HCM400
0.75KW/220V
100Kg/h
60Kg
650*510*700mm

3. Potato Chips Blanching Machine

Feature

1.Bleaching temperature with 70ºC is automatically controlled.

2. Blanching time can be adjustable.

3. Used to kill harmful bacteria and keep original
flavor in food.

Technical Data

Specification
Power
Weight
Dimensions
HCB100
15kw/380v
50kg
1310*650*700mm

4. Chips Dehydrating Machine

Features

1. Through the fast rotating barrel to remove the surface water.

2. With anti-shock system for safety



Technical Data

Specification
Power
Capacity
Weight
Dimensions
HDM500
0.75kw/380v
8-10kg/batch
400kg
940*560*830mm
HDM600
1.1 kw/380v
15-20kg/batch
500kg
1050*660*930mm

5. Potato Chips/French Fries Frying Machine

Features

1. Adopts oil-water mixture technology which can save oil and power consumption. Oil and water are automatically separated after mixing, oil on the top to fry food, water at the bottom to receive waste.

2.Frying temperature can be controlled freely

3. Over-temperature protection device for operation safety

Technical Data

Specification
Power
Oil Groove Size
Dimensions
Weight
HFM500
9kw/380v
500*500*400mm
880*620*930mm
60kg
HFM1000
21kw/380v
1000*500*400mm
1380*620*950mm
120kg

6. Potato Chips De-oiling Machine

Features

1. Through the fast rotating barrel to
remove the surface water.

2. With anti-shock system for safety


Technical Data

Specificaiton
Power
Capacity
Weight
Dimension
HDM-500
0.75kw/380v
8--10Kg/batch
400 kg
940*560*830mm
HDM-600
1.1 kw/380v
15--20Kg/batch
500 kg
1050*660*930

7. Fried Potato Chips Flavoring Machine

Specification
Power
Weight
Dimensions
HTM80
0.75kw/220v
90kg
1000x800
x1380mm
HTM100
1.1kw/380v
110kg
1020x1070
x1430mm

8. Nitrogen Potato Chips Packaging Machine

Spec
HPM400
HPM500
Power
1kw/380v
2 kw/380v
Capacity
60-160 times/h
90-360 times/h
Weight
180 kg
230 kg
Dimension
1050*650*855mm
1050*650*855mm
Sealing Size
400*10/2 mm
500*10/2 mm


Process Flow of Semi-automatic Potato Chips Making


Designing Data
Chips
Potato
Oil Consumption
Water Consumption
30kg/h
90--100 kg/h
2 kg/h
50 kg/h

Operation Technical Data

Potato Chips
French Fries
Blanching time:
7-15 minutes
7-15 minutes
Frying time:
6 minutes
8-10 minutes
Blanching temperature:
70℃
70℃
Frying temperature:
180℃
180℃
