Specifications
1. Argon tig welding machine has small measurement.2. The welder is portable,multi-functions,stable current,simple operation
♣TIG Mini Welder( tig welding machine) Characteristic:
1.Small measurement, portable and multi purpose welder.
2.HF arc start, simple operation, strong welding penetration.
3.MMA have "arc force" adjust function.
4.Easily arc-starting, stable current, high speed of dynamic-response;noise-free;little
spark, beautiful welding seam.
5.Can weld many sort of metal such as stainless steel, alloy steel copper etc.
♣Technical Parameter:
|
Type Content
|
WS-160 |
Input Power Voltage(Freguency)(V;HZ) |
220±15%50/60 |
No-load Voltage(V) |
43 |
Output Current Adjustment Range(A) |
10-160 |
Rated Output Voltage(V) |
16.4 |
Rated Duty Cycle(%)25 |
60 |
No-load Consumption(W) |
40 |
Efficency(%) |
85 |
Power Factor(COSφ) |
0.93 |
Weight |
8 |
Measurement (mm) |
371×155×295 |
Insulation Class |
F |
Protection Class |
IP23 |
Post-welding Gas Blow Time |
2.5/5 |
Suitable Welding Thickness(mm) |
0.3-5 |
Client's own logo will be accepted when the quantity is above 50pcs.
