hydraulic damper cabinet hinge
- Cabinet Concealed Hydraulic Soft Close Half overlay Hinge
- For Frameless Cabinets with 14mm-23mm Doors
- 35mm Cup Size.
- Equipped with Hydraulic Soft Close Mechanism.
- Reinforce supporting arms. Clip On Mounting Plate Included.
See more product details
Long arm style cabinet hinge. Hydraulic Soft Close Silent System is built into the hinge, cabinet door will close slowly and quietly even you slam the door! Reinforce supporting arms.
Made for 14mm-23mm door and side panel. Hinge features full adjustability after installation. Hinge fits into a "cup" drilled into the back side of the cabinet door.
The cup diameter is 35mm (1-3/8"). For cabinets with half overlay doors and no face frame (frameless cabinet).
Hinge is made from steel and is nickel plated. Reveal: a 3mm bore distance (distance between the edge of the door and the edge of the 35mm cup drilled in the back of the door) will produce a reveal of 1mm.
The reveal is the gap between the edge of the door and the cabinet side panel. Clip-on mounting plate included. The hinge and the mounting plate attach to each other by snapping together without the use of additional fasteners.
Specification
|
Type: cabinet hinge |
Place of Origin: Jiangmen China (Mainland) |
Brand Name: OEM |
Application: furniture | ||
Material : Steel | ||
Model : ECH013 | ||
Finish & Size: SN | ||
Function |
hydraulic damper cabinet hinge |
|
| Depth of hinge cup | 11.3mm |
|
| Diameter of hinge cup | 35mm |
|
| Door Thickness | 14mm-23mm |
|
| Door dimension | 3mm-7mm |
|
Standard export package |
White box, Soft foam plastic bag |
|
Inner packing |
Soft foam plastic bag , color box and blister packing |
|
Delivery |
35 working days |
|
cabinet hinge picture
