Help Center10KA 2P 40A FL7-40 Electronic Type RCBO Residual Current Operated Circuit Breakers With Intergal Overcurrent Protection
Related Products
-
Magnetic Type 2 Pole 40A 30mA MNL New ID Model RCCB ELCB RCD Residual Current Circuit BreakerUS$ 4.5 - 6MOQ: 200 Pieces -
Electro-magnetic Type 4 Pole 25A-63A 230/400V MNL Model RCCB Residual Current Circuit BreakersUS$ 6.4 - 8MOQ: 200 Pieces
-
Russian Hot Sale 2 Pole 40A 30mA NFIN Y30 RCD Residual Current DevicesUS$ 3.5 - 6MOQ: 200 Pieces
-
4 Pole NFIN RCD 25A-63A 230/400V Residual Current Devices Y30US$ 4.8 - 8MOQ: 200 Pieces
-
4 Pole ID Model RCCB ELCB RCD 16A-100A 230/400V Residual Current Circuit BreakersUS$ 6.5 - 8MOQ: 200 Pieces
- Residual Current Circuit Breaker With Overcurrent Protection
- Electronic type
- Compact structure, small volume, (two modules in width)
- With short circuit, overload and residual current protection
- Action function has nothing to do with main circuit voltage
- With center line cut-off functions, it is safer and more reliable.
- With double functional connection terminals, it has strong connection ability.
- With contact state indicator, it is easy to recognize the contact situation.
- Different handle colors are used to indicate different rated current.
- High breaking capacity:10KA
- With wide range of rated current, it can be used as family main switch
- United accessories series
- Type C can protect the error tripping caused by electric equipment
Model: Electro-magnetic type , Electronic type
- Residual Current Characteristics: A, AC
- Number of Poles: 1P+N, 3P+N
- Standard: IEC61009-1 (EN61009-1)
- Rated Voltage(Un): 230(240)/415V AC
- Rated Current(In): 6,10,16,20,25,32, 40A
- Rated Residual Operating Current ( IΔn): 10,30,100,300mA
- Rated Residual non-operating current IΔno: 0.5IΔn
- Breaking capacity: 10KA
- Release Tripping Curve: B,C,D
- Residual Current Tripping Time: Instantaneous tripping≤ 0.1Sec.
- Residual Operating Current Range: 0.5IΔn~IΔn
- Electro-mechanical endurance : 4000 cycles
- Connection capacity : Rigid conductor 25mm2
- Connection terminal : Screw terminal, Pillar terminal with clamp
- Fastening torque : 2.0Nm
- Installation : 35mm DIN rail mounting
Q 1. What's the payment term?
A. We accept T/T, L/C, Western Union, Cash
Q 2. What's the delivery time ?
A. Usually it would take about 25 days for production
Q 3. What is the standard of package?
A. Export standard package or special package according to customer requirement
Q 4. What kind of product quality your factory offer?
A. We offer most competitive prices with best quality, copper coil with silver contact.
Q 5. Do you accept OEM and ODM business?
A. We do,for OEM service please send us your authorization, also your quantity should large enough.
Q 6. Could you offer certificate of origin?
A. We can prepare relative documents to foreign affairs office or other office to apply the certificate.
Q7. What kind of certificate you have ?
A. Our company already achieve ISO, and for products, we have CE, SEMKO,CB, BSI, GS, TUV, VDE.
Your acceptance of the freight collect means the samples provided to you free.
Your order, our responsibility.
We will keeping improvement of technology in daily life, offer you excellent products, competitive prices, humanized service.
