Specifications
silicone tubular heater1,Various dimensions
2,Good stability
3,Short lead time:7-10days
4.Certificates:CE,RoHS,UL
Flexible Heating Plate Silicone Tubular Heater
Technical Data:
Rated Power |
W |
Lead Length |
200mm |
Rated voltage |
12V—380V |
Wire tension |
15N×15N |
Maximum size |
1000m—1200m |
Minimum size |
20mm×20mm |
Ambient Temperature |
--60-----250°C |
Highest temperature |
250°C |
Maximum thickness |
1.5mm—4mm |
Withstand voltage |
1.5KV |
Insulation resistance |
≥5MΩ |
Size deviation |
±0.5percent |
Power deviation |
±5percent |
Wire Type |
Silicone braided wire |
Silicon rubber electric heating plate produced by the company is extremely thin, light and flexible. And the heater with the silicon rubber electric heating plate can transfer heat to any required place. In processing, it can improve heat transfer, accelerate temperature rising and reduce power need. Glass fiber-reinforced silicon rubber can ensure the heater to be stable in dimension, without losing flexibility.
(1) Design according to actual shape and dimension, and ayour equipment.
(2) Moisture-proof chemical defense silicon rubber material makes the service life of heater much longer.
(3) It can be simply pasted or attached to your component by vulcanizing, adhesive or fastener, etc.
Silicon Rubber Heater :
1,size: Max:1000 mm*1000 mm.Min.20mm*25mm
2,Standard Thickness 1.5mm
3,nickel 80% wound wire or nickel 80% foils(thickness 0.05 mm~0.10mm)inside
4,variety of shapes, can be customized
5,various types of lead wires and other terminations.
6,fast heating:3~5w/cm2
7,high thermal efficiency, save energy
8,wide range of temperature,-60°C~250°C
9,Long service time
Application of Silicon Rubber Heater :
1. Industrial equipment, pipelines, barrels, tanks, etc.
2. Outdoors telecommunication equipment
3. Medical equipment and devices
4. Outdoors electronic devices
5.Thermal imaging of imaging equipment
6. Case protection under cold and moist environment
7. Industrial ovens and thermal processing equipment
8. Ventilator supports
9. Laminating equipment
10. Vessels
Temperature VS. Time:
This picture shows the surface temperature of a silicon rubber heater when the heater does no be insulated and be suspended in static air at a temperature of 20 DEG C. The data is obtained on the basis of taking a 1.4mm thick standard structure as reference. Note: It can be customized according to the required voltage, power and specifications of customers,
Specification;End surface plate is simply treated with moisture protection, and can not be used after putting in water or frosting place at a long time.
