Cartridge Heating Resistor Air Parking Heater
- 200000 Piece / Pieces per Month
- Shenzhen HK
- T/T Credit Card PayPal
- Heater Core Heater Welding Gun Heater Element
- Industrial Diesel Heater /Agricultural Vegetable Planting/Aquaculture Industry Heater
- Preheating equipment for hardbandig welding
- Heater Core Heater Welding Gun Heater Element
- DL-3 model electric air heater with upper outlet and lower inlet
- DL-2 model electric air heater with Left-Right Circulation
Product Details
Condition: | New | Type: | Other, Cartridge heater, Air Parking Heater | Power Source: | Electric |
Place of Origin: | Guangdong, China | Brand Name: | Detai | Model Number: | DL-0044 |
Dimension(L*W*H): | As your required | Weight: | Based on the dimensions | Voltage: | 12-240v |
Power(W): | 200-30000w | Certification: | UL;CE;CSA;ISO9001:2008;Rohs,CQC,CSA | Warranty: | 1 year |
Product Description
Specifications
air parking heater1.With UL,CE,ISO approval
2.Instant heating
3.Stainless steel heater element
4.Meet EU & US standard.
Cartridge Heating Resistor Air Parking Heater
Recommended for temperatures up to 750°C
All Cartridge Heaters are available with a built in Thermocouple Type J or K
Sheath Material | SUS 304/316/ Incoloy 840 |
Spirals | Nickel - Chrome |
Insulation | Magnesium Oxide Powder |
Voltage Supply | 12V to a maximum of 480V |
Maximum Temperature | 750 °C |
Resistance Tolerance | +10% - 5% |
Wattage Tolerance | +5% - 10% (closer tolerances are available upon special request) |
(1). Hot!!! stainless steel tubular heating element
(2). Water electric heater element
(3). Electric heating element
(4). Tubular,flange heater,stainless steel,inconel sheath
(5). Kanthal wire inside, high pure MgO
Tubular heaters are available in Copper, SS304, SS 310, SS316, SS321, Inconel & Incolloy sheath. Tubular heating elements are available for various industrial & domestic applications. We built every technically possible heaters as per your requirement.
Features
(1). Nickel Chrome resistance wire
(2). Immersion Heaters are available with screw plug flanges
(3). Air Heaters are available with MS or SS fins
(4). Tubular heating elements with additional teflon sleeving is available for heating corrosive chemicals
Applications
(1). Plastic Processing machinery.
(2). Water and Oil Heating Appliances.
(3). Packaging machineries
(4). Vending Machines.
(5). Dies and Tools.
(6). Heating Chemical Solutions.
(7). Ovens & Dryers
(8). Kitchen equipments
(9). Medical equipments
(10).Used in many other applications.
Specification Requirements for Ordering
Please note that Detai manufacture to customer specification. There are many lead options available, including Glass Fibre Leads, Silicon Rubber Leads, PTFE Leads, Ceramic Beaded Leads, Braided Leads and Conduits. Please advise us of the type of leads preferred. If you would like some assistance or advise on the correct lead to use, please do not hesitate to ask.
1.Type of Cartridge Heater ( please refer to Termination Options ).
2.Ø of Cartridge Heater.
3.Overall length for a straight Cartridge Heaters.
4.Wattage & Voltage
5.Lead type ( glass fibre / PTFE ) & lead length.
