Specifications
heater for sterilization1.ISO,UL,CE,CSA
2:Stainless steel 304,321,316
3.Competitive factory price
4.For oven,air condition
Air Heating Finned Strip Heater For Sterilization
Length |
Wattage |
Watt Density |
||
in |
mm |
W/in2 |
W/cm2 |
|
10 ½ |
266.7 |
500 |
34 |
5 |
10 ½ |
266.7 |
725 |
45 |
7 |
12 |
304.8 |
900 |
40 |
6 |
14 |
355.6 |
750 |
28 |
4 |
14 |
355.6 |
1100 |
37 |
6 |
23 ¾ |
603.3 |
2200 |
30 |
5 |
30 ½ |
774.7 |
2800 |
29 |
5 |
42 ½ |
1079.5 |
4150 |
31 |
5 |
Construction features
The construction of finned strip heaters consist of wound coils placed in special ceramic insulators engineered to generate the most power possible. These coils are then connected to one of the end depending on the mounting required. The space left inside the stainless steel rectangular tubing is then filled with high priority magnesium oxide in order to ensure conductivity and strength. The last step is to mount the fins which have been designed to maximize heat transfer.
Efficient and dependable for air heating, surface heating and radiant heating applications Available in steel, stainless steel 10/32 threaded screw terminals Mounted tabs Sealed ends to prevent moisture Capable of operating up to 1200ºF (650ºC) Available with different terminations to meet your application.
| Typical Applications | |
|
Duct heating Space heaters Drying Ovens Food processing Shrinking Tunnels |
Air heating Heat curing dehumidifiers Pharmaceutial Hot sealing
|
|
Ratings Maximum temperature: 1190ºF (640ºC) Nominal Watt density: 45 Watts / in2 | |
| How to order |
|
* Determine Wattage and available Voltage * Select heater length and termination * Standard wire 1 1/2” |
