Industrial 1000kgs Electric Mini Garbage Truck

Name: Industrial 1000kgs Electric Mini Garbage Truck
Brand: HIghstar
SKU: 121708167
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Capacity (Load):

1 - 10t

Size:

4600*1500*1960mm

Anhui Huaxin Electric Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Capacity (Load) 1 - 10t

Size 4600*1500*1960mm

Gross Vehicle Weight 1250

Place of Origin Anhui, China

Brand Name HIghstar

Model Number ZT4308

Product Description

Key Components

Item	Description
Controller	imported from USA directly
Motor	AC motor Chinese brand
Battery	Lead Acid battery maintenance free
Charger	72V/30A

Performance

Dimensions

Item	Description
Overall dimensions (mm)	4600(3930)14702050 (LxWxH)
Rear garbage box dimensions (mm)	*2970(2270)1280520* (LxWxH)
Min .ground clearance (mm)	190
Wheelbase (mm)	2420(1780)
Front wheel tread (mm)	1240
Rear wheel tread (mm)	1240

Body and Frame

Item	Description
Frame & Chassis	Welded steel framework with sand blasting and painting
Cabin	Aluminum frame with FRP cover sheet and glass window
Front windshield	Laminated glass with wiper
Seat	Reborn sponge with artificial leather,
Floor	Skid proof leather
Rear garbage box	Steel material, with hydraulic lifting function, with side lifting function
Battery sliding system	Steel frame with sliding wheel
Beverage holders	1 cups holders
Side rear view mirror	2pcs, manual adjustable

Electric System

Item	Description
Lights	12V, headlight (H/L beam), front turning light, Rear taillight (brake light and rear turning light)
Horn	Electric horn, 12V
Reverse buzzer	Electric, 12V
DC/DC converter	72V/12V
Audio system	Radio with MP3 receiver, with two waterproof speaker
Digital Meter	with Current meter, volt meter, speedometer and various indicators

Steering and Suspension

Item	Description
Brake System	4-wheel hydraulic drum brake with hand park brake,
Accelerator	Resistance type, stepless speed change
Front suspension	non-independent suspension, cylinder hydraulic vibration absorber and leaf spring
Rear suspension	integrated rear end, steel plate spring suspension, cylinder hydraulic vibration absorber
Transmission system	Clutch, 4F+1R gear box, transmission shaft
Wheel & Tyre	155R12C tubeless tire, 4J*12 steel rim
