720P/960P/1080P High Definition Analog CCTV Camera, 1.0 Megapixel and 1.3 megapixel AHD Camera, 1.0mp/1.3mp AHD CCTV Camera
Specifications:
1/3" 1.3Megapixel CMOS
25/30fps at 720P/960P, Built-in IR Cut
High speed, long distance real-time transmission over 500m
3.6/6/8mm Lens
30pcs φ5 IR LED
IR Distance20m
IP 66 waterproof
Metal
Support OSD
Features:
Analog HD Camera, AHD Technology
720P/960P/1080P@25/30fps,
High speed, long distance real-time transmission over 500m via coxial cable
Day/Night(ICR), AWB, AGC, BLC, 2D-DNR
Built-in IR Cut,Smart IR, DC12V
Parameters:
Model |
YCG-6030A |
||
Image Sensor |
1/4" COMS,1.0M Pixel |
1/3" Sony COMS 1.3M Pixel |
|
DSP+CCD |
Nextchip 2431H+OV9712 |
Nextchip 2431H+AR0131 |
Nextchip 2431H+SONY225 |
Effective Pixels |
PAL/NTSC: 1280*720 |
PAL/NTSC: 1280*960 |
|
Scanning System |
NTSC: 525 lines, 60 fields/sec |
||
Sync System |
Internal |
||
MIN Illumination |
0.1 Lux / F1.2(0Lux / IR ON) |
0.03 Lux / F1.2(0Lux / IR ON) |
0.01 Lux / F1.2(0Lux/IR ON) |
S/N Ratio |
52dB (AGC OFF) |
||
Gamma Correction |
0.45 |
||
Electronic Shutter |
NTSC: 1/30~1/50,000 sec |
||
OSD |
Support |
||
White Balance |
AWB/ATW/AWC/INDOOR/OUTDOOR/MANUAL |
||
Gain Control |
0-15 |
||
BLC |
BLC/HSBLC/OFF |
||
DNR |
2DNR, 3DNR |
||
DWDR |
ON/OFF/AUTO |
||
Day/Night |
Auto/B&W/Color/EXT |
||
Mirror |
ROTATE/OFF/MIRROR/V-FLIP |
||
NEG. IMAGE |
ON/OFF |
||
CAM TITLE |
ON/OFF |
||
DEFECT |
ON/OFF |
||
Motion Detection |
ON/OFF(4 Programmable Zone) |
||
OSD Language |
ENG,GER,FRA,ITA,SPA,POL,RUS,POR,NED,TUR,CH1,CH2 |
||
IR LED |
30pcs φ5 IR LED |
||
Video Output |
AHD |
||
IR Distance |
20m |
||
Lens |
3.6/6/8mm Lens |
||
Operation Temperature |
-20 °C ~ 50°C |
||
Operational Humidity |
Within 95%RH |
||
Material |
Metal |
||
What's AHD?
AHD (Anaglog High Definition) is an over-coaxial-cable analog HD Video transmission standard which developed in-house.
The technology renders two HD video formats---1920H(1920X1080)&1280H(1280X720) by progressive scanning.
products manufacturing
24 hours online technical support
customised product sourcing
free technical training
2 years product warranty after-sale service
1% of spare parts for you, in case of broken during shipping
Q: How long is the warranty?
A: 2 -years-warranty since delivered out.
Q: How long is the delivery time?
A: Sample order 3-5 working days, bulk order 7-15 working days.
Q: Why do you choose us?
A: Choose UCHUANGU; Choose a qualified CCTV Products manufacturer!
We will try our best to find the products you need, we will provide you with the most satisfactory service.
If you want to know more, You can contact us. We also welcome you to visit our factory in Shenzhen.
