Specifications
1. Barcode scanner Zebex Z-3220 Handheld Linear Image Scanner2.Zebex barcode scanner
Zebex Z-3220 Handheld Linear Image Scanner
The sleek new Z-3220 delivers outstanding scanning performance at a competitive price. Specially designed for first time users, the scanner is ergonomically shaped and employs a field replaceable cable allowing for fast and easy disconnection from the host. With its newly improved decoding capability, the scanner provides an exceptional first-read-rate, making it ideal for retail applications.
• Proprietary Ultrascan decoding technology
• Light and rugged design
• Advanced image capture technology
• Multi-interface communication • Ideal for beginners
Zebex Z-3100 OPERATIONAL | |
Light Source | 625 nm visible red LED |
Optical System | 2,500 |
Microprocessor | 32 bit |
Depth of Field | 0 – 50 mm (0.33 mm, PCS=90%) |
Scan Angle | 42° |
Scan Rate | 150 scans per second |
Minimum Bar Width | 0.1 mm (4 mil) (0.07 mm actually) (Code 39, PCS=90%); more than 100 mm on 0.125 mm barcode |
Print Contrast | Min. 25% @ UPC/EAN 100% |
Indicators (LED) | Two-colors LED |
Beeper Operation | Programmable tone & beep time |
System Interfaces | Keyboard, RS-232, HID USB, USB Virtual COM, wand |
PHYSICAL | |
Dimensions | 165.7 × 72.5 × 54.0 mm (device only) |
Weight | 100 g (device only) |
Cable | standard 2M straight |
POWER |
|
Input Voltage | 5 VDC ±5% |
Operating Current | 90 mA typical |
ENVIRONMENTAL | |
Operating Temperature | 0°C – 50°C (32°F – 122°F) |
Storage Temperature | -20°C – 60°C (-4°F – 140°F) |
Humidity | 5% – 95% RH (non-condensing) |
Light Levels | 6,000 Lux (fluorescence) |
Drop Durability | Designed to withstand 1.5M drops |
1 year factory warranty
Over the past ten years, we are always an authorized distributor of Metrologic barcode scanners,Symbol barcode scanners,Cipherlab portable data collection terminals ,TSC barcode printers and Zebra barcode sprinters. Shenzhen Barcodescan Electronics Co., Ltd. continuously increases our importance in the barcode and electronic products market by offering appropriate prices and sufficient services. We have been always worked hard to earn a reputation for being a dedicated, reliable, and customer-oriented company. We are dedicated in providing total business solutions to meet the demands and challenges of today's competitive market.
FOB Shenzhen,TT
