Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > Citizen Printer Cl-s400dt-r Barcode Printer With Paper Holder and Roll Media
Citizen Printer Cl-s400dt-r Barcode Printer With Paper Holder and Roll Media
Negotiable
MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Dot-matrix
Style:
Black And White
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Barcode Printer Citizen Cl-s621 Label Printer Citizen Barcode PrinterNegotiableMOQ: 1 Piece -
Label Printer Citizen CL-S700R Barcode Label PrinterNegotiableMOQ: 1 Piece
-
Label Printer Sato GL4e Series Barcode PrinterNegotiableMOQ: 1 Piece
-
Barcode Printer Sato CL408e CL412e Label PrinterNegotiableMOQ: 1 Piece
-
Label Printer Sato Barcode Printer M84ProNegotiableMOQ: 1 Piece
Products Status
Stock
Type
Dot-matrix
Style
Black And White
Use
Barcode Printer
Interface Type
USB
Max Paper Size
19.5 - 118.0mm
Black Print Speed
6 ips
Max. Resolution
203 dpi
Brand Name
CITIZEN
Model Number
CL-S400DT-R
Place of Origin
Japan
Specifications
1.Citizen printer cl-s400dt-r barcode printer with paper holder and roll media2.Citizen barcode label printer
Citizen barcode label printer cl-s400dt
Product Description
Features
- Hi-Lift mechanism of easy ribbon and media loading
- Self-contained metal mechanism for durable operation
- Auto Emulation of Zebra and Datamax as installed as standard
- BASIC interpreter for code conversion and support for other ticketing emulations
- Adjustable media sensors for tags with unusual cut-outs or black marks
- Standard tear-bar for perforated tags or optional autocutter
- Internal USB, Serial, Parallel and network interfaces configurations
- Media roll holder or fanfold stacked media
Easy operation and media change
Tags and labels can be stacked behind the pritner and easily changed with the Hi-Open print mechanism.
Fanfold or roll media available
The CL-S400DT can handle fanfold tickets as well as standard roll media for labels or receipts.
Easy read LCD panel
The LCD panel allows quick and simple configuration and also flashed red when an error occurs quickly alerting the operator.
Specifications
| CL-S400DT | ||
|---|---|---|
| Printing method | Direct thermal | |
| Resolution (approx) | 203 dpi (8 dots/mm) | |
| Print speed (max.) | 6 ips | |
| Print width (max.) | 104mm | |
| Print mode | Batch mode | Normal printing (Single or multiple sheets) |
| Teaf off mode | Feeds back media to the tear-off position after printing is completed. | |
| Cut mode (*1) | Prints while cutting at designaetd number of sheets. The following two kinds of cut mode operations are avaialble. (1) Backfeed (2) Cut through | |
| Peel mode (*1) | Peels labels from the liners after printing them | |
| Media | Media type | Roll, fanfold (Continuous media, die-cuts media, continuous tags, copntinuous tickets) |
| Type of media | Thermal-transfer media | |
| Recommended media | Heat-transfer media: Label media (150LA-1 Ricoh), Tag media (TB2E0V Mitsubishi Paper) | |
| Media width | 19.5 - 118.0mm (min. to max.) | |
| Media length | 6.35 - 812.8mm (min. to max.) | |
| Media thickness | 0.0635 - 0.254mm (min. to max.) | |
| Label width | 19.5mm (min.) | |
| Label pitch (*2) | 6.35mm (min.) | |
| Roll media diameter | External diameter: 127mm (max.) Media core: 25.4 - 76mm | |
| Barcode (Datamax® emulation) | One-dimension | Code 3 of 9, UPC-A/E, EAN-13 (JAN-13), EAN-8 (JAN-8), Interleaved 2 of 5, Code 128, HIBC (Modulus 43-used code 3 of 9), Codebar (NW-7), Int 2 of 5 (Modulus 10-used Interleaved 2 of 5), Plessey, Case Code, UPC 2DIG ADD, UPC 5DIG ADD, Code 93, Telepen, ZIP, UCC/EAN128, UCC/EAN128 (for K-MART), UCC/EAN128 Random Weight, FIM |
| Two-dimension | UPS Maxi Code, PDF-417, Data Matrix, QR Code, Aztec, RSS | |
| Barcode (Zebra® emulation) | One-dimension | Code 11, Interleaved 2 of 5, Code 39, EAN-8, UPC-E, Code 93, Code 128, EAN-13, Industrial 2 of 5, Standard 2 of 5, ANSI CODABAR, LOGMARS, MSI, Plessey, UPC/EAN Extensions, UPC-A, POSTNET, Planet |
| Two-dimension | Code 49, PDF-417, CODE BLOCK, UPS Maxi Code, Micro PDF-417, Data Matrix, QR Code, RSS, TLC39 | |
| Font (Datamax® emulation) | 1. Seven kinds of fixexd pitch font 2. OCR fonts (OCR-A, OCR-B) (*3) 3. Proportional fonts 4. True type™ rasterizer | |
| Font (Zebra® emulation) | 1. Five kinds of fixexd pitch font 2. OCR fonts (OCR-A, OCR-B) (*3) 3. Proportional fonts 4. True type™ rasterizer (*4) | |
| Control language | CITIZEN original language | |
| Media sensor | Transparent sensor, Reflective sensor, Label peeling sensor (*1) | |
| Standard interface | Serial (RS-232C), USB (version 2.0) | |
| Optional interface | Parallel (IEEE-1284) LAN (10-BASE-T/100-BASE-TX) | |
| Control panel | Back-lit LCD and 4 buttons | |
| CPU | 32 Bit RISC CPU | |
| ROM | Flash ROM 8MB (User area: 1MB) | |
| RAM | Datamax® emulation | SDRAM 16MB(User area: 1MB) |
| Zebra® emulation | SDRAM 16MB(User area: 4MB) | |
| Power | 220-240V 50/60Hz | |
| Temperature and humidity | Operating | Temperature: 0 to 40 °C Humidity: 30 to 80% (no condensation) |
| Storage | Temperature: -20 to 60 °C Humidity: 5 to 85% (no condensation) | |
| External dimension (W×D×H) | 206 × 148 × 150mm | |
| Weight (approx.) | 3.5 kg | |
Packaging & Shipping
Our Services
1 year factory warranty
