Help CenterHydraulic Ceramic Three Roll Milling
Related Products
Specifications
the baffle palte's material is German Teflon materialrollers are equipped with adjustable efficient closed cooling system
Three roller ginder SYPT
The three roll mill is mainly used for refining high viscosity materials in oil paint, printing ink, color paint and plastic industries.It is especially suitable for processing materials with high viscosity and fineness. The three rolls run at different speeds and the materials are squeezed into the spaces between different rolls in order to get the grinding and refining effects.
WORKING
SYPT is composed of three horizontally positioned rolls rotating in opposite directions and at different speeds. The materials to be milled is placed between the feed and center rolls and gets transferred from the center roll to the apron roll by adhesion. Milled materials are scraped from the apron mill by a take-off knife. The cycle can be repeated to improve dispersion or until particle size equilibrium is reached. The shear forces between adjacent rolls generate the dispersion. Decreasing the distance between rolls produces greater shear but also reduces throughput.
Advantage:
1. Pneumatic three roll grinding is pollution-free, explosion-proof grade higher, it fits for the high lever of security area even better.
2.It also can be equipped with PLC control system according to the customer requirement. Advanced graphics interface touch control screen makes all operation parameters and machining process visualized, then it can automatically control the roll temperature, speed, pressure and clearance.
3.Roller pressure and clearance adopts electronic control, ensuring the production, monitoring more precise and machining process can be repeated. It also can be equipped with remote control system according to the customer requirement.
| roller dia mm | working length mm | slow speed | middle speed | fast speed | moter power | general pressure | pump power | weight | overalsize |
| 150 | 300 | 26 | 80 | 0-240 | 5.5 | 6.3 | 1.5 | 950 | 1030x900x1100 |
| 200 | 550 | 55 | 167 | 0-400 | 11-15 | 6.3 | 1.5 | 1200 | 1250x1250x1350 |
| 260 | 650 | 44 | 133 | 0-400 | 18.5-22 | 6.3 | 1.5 | 2400 | 1670x1110x1200 |
WORKING
ZILI ROLLERS:
CE
MAIN CUSTOMER
