ST-1400CX-3 Good General Ashing Furnace

ST-1400CX-3 Good General Ashing Furnace thumbnail-1
ST-1400CX-3 Good General Ashing Furnace photo-1
US$ 1,975 - 6,753 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
SuTong
Model Number:
ST-1400CX-3
Contact Supplier Request Quote Chat Now
Zhengzhou Sutong Electric Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name SuTong
Model Number ST-1400CX-3
Power Other, Electronic, 2.9Kw

ST-1400CX-3 Good general ashing furnace



Detailed Specifications:

  • Chamber size:200x200x200mm (W xH×D)
  • Heating elements: SiC heating elements
  • Maximum Temperature: 1400.C
  • Working Temperature : 1300.C
  • Rated Power:4.5KW
  • Thermocouple:Stype



Chamber size

200x200x200mm (W xH×D)

Heating elements

SiC heating elements

Elements layout

2 sides

Temperature controller

30 segments programmable and PID numerical control

Furnace structure

Double shell with fan cooling

Thermocouple

S type

Heating Rate

0.1~15.C/min  (suggest </=10.C)

Maximum Temperature

1400.C

Working temperature

1300.C

Temperature  accuracy

+/- 0.5.C

Working Voltage

Single-phase,AC,110/120/208/240V(choose any)

Power frequency

50H/60Hz(choose any)

Rated Power

4.5KW



Standard size:

Model

Chamber size(WxHxDmm)

Max. Temperature

Rated Power

ST-1400CX

150x150x150mm (6"x6"x6")

1400.C

2.5

ST-1400CX

150x150x200mm (6"x6"x8")

1400.C

2.9

ST-1400CX

200x200x200mm (8"x8"x8")

1400.C

4.5

ST-1400CX

200x200x300mm (8"x8"x12")

1400.C

5.5

ST-1400CX

250x250x300mm (10"x10"x12")

1400.C

7.5

ST-1400CX

300x300x400mm (12"x12"x16")

1400.C

12

ST-1400CX

350x350x400mm (14"x14"x16")

1400.C

14.5

ST-1400CX

400x400x400mm (16"x16"x16")

1400.C

17.5

ST-1400CX

500x500x500mm (20"x20"x20")

1400.C

27.5



 Aplications:

  1. Crystallize;
  2. Sintering or Roasting or Forging or calcining;
  3. Ashing;
  4. Heat treating or Preheating;
  5. Quench or Hardening or Austemper
  6. Annealing or Tempering or Normalizing
  7. melting or smelting
  8. Synthesis and degradation or pyrolysis or decomposing

ST-1400CX-3 Good general ashing furnaceST-1400CX-3 Good general ashing furnace





Packing&Shipping



Plastic paper inside, Polyfoam filled, Wooden box outside.

Products can be shipped by FedEx, UPS, TNT,DHL,EMS too door service, air transport etc.

ST-1400CX-3 Good general ashing furnaceST-1400CX-3 Good general ashing furnace



ST-1400CX-3 Good general ashing furnace

 Our Services

  • Sutong can load container at Qingdao, Tianjin, Shanghai etc.
  • Sutong provide shipping method: Courier service, Air transport, Sea transport
  • Sutong accept order: Full container cargo load, LCL and sample order
  • Sutong provide service:EX-WORK, FOB, CIF, C&F, Door to Door etc
  • Sutong has complete quality control system and after-sale service

Payment



L/C T/T, West union,etc.



Warranty

  • Our products are warranted to be free from defects in materials or workmanship for one year from the date of purchase. Within this period, Across International will, at its sole options, replace any components that fail in normal use. Such replacement will be made at no charge to the customer for parts, provided that the customer shall be responsible for any transportation cost.
  • This warranty  does not cover consumables and failures due to abuse, misuse, accident or unauthorized alteration or repairs.
  • Replacement will be shipped to you after photo or other evidence are provided and investigated
