PC Computer Power Supply ATX 230W

Specifications

Computer cabinet 230W power supply

Specification

20+4P, 2B/1S,2SATA,P4

• 1.2M Continental Power cable
• 12CM Fan
• Output line:400MM
• 0.5MM For Intel ATX12V Ver1.3, output :200W(300W Max)
  • For Dual Core CPU
  • High efficiency
  • Low ripple & noise
  • Output over voltage protection
  • Short circuit protection on all outputs
  • Internal 8CM FAN
  • 100% burn-in under high ambient temperature(50°C)
  • MTBF:80k hours at 25°C
•
  Input Specification :
  • AC INPUT:115V/230V
  • Frequency: 47-63Hz
  • Current: 5A @115Vac 60Hz ; 3A @230Vac 50Hz
•
  Output Specification :
  • Color: Silver
  • Cooling System: SPEED: 2200RMP(+/-10%)
• DIMENSION:140*150*86mm
• Noise: 19dB at 2200rpm
• P.G Signal: 100-500ms
•
  • Hold-up Time: 17ms(min)
  • Efficiency: 72%
  Galvanized
•
•
