Home > Products > New Products > China Qingzhou SZM New Design Front End Loader 928 Wheel Loader With CUMMINS Engine 92kw DEUTZ Engine Joystick Quick Hitch
China Qingzhou SZM New Design Front End Loader 928 Wheel Loader With CUMMINS Engine 92kw DEUTZ Engine Joystick Quick Hitch
Negotiable
/ Set
1 Set(Min. Order)
- qingdao
- T/T
You May Like
-
Zl-30 Wheel Loader 936L for Export With Hydraulic Joystick
-
New Loaders Backhoe 928 by Pilot Control With High Quality
-
ZL-12 Mini Lift Loader With Option Attachments for Exporting
-
Loaders Made in China Qingzhou SZM Zl-12 Mini Wheel Loader912 With Euro3 Engine Quick Change Joystick
-
4WD Mini Wheel Loader ZL16 Hydraulic Operation Joystick/quick Hitch With CE
-
Wheel Loader Zl50
Product Details
| Condition | New | Brand Name | SZM | |
| Model Number | 928 | Place of Origin | Shandong, China | |
| Type | Front Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | (Long * Breadth * High) 5980*2080*2850 | Rated Load | 2000kg | |
| Certification | CE |
Product Description
| Specification | overall weight(kg) | 5700 |
| L×W×H(mm) | 5980×2080×2850 | |
| rated bucket capacity(m3) | 1.3 | |
| Rated load(kg) | 2000 | |
| Maximum dump height (mm) | 2850 | |
| Wheelbase | 2480mm | |
| thread | 1670mm | |
| Max breakout force | 70KN | |
| Total time | 11.3s | |
| Bucket indicator | Yes | |
| Engine | Model | Cummins4BT3.9-C100 |
| optional | YTR4108G92 | |
| Type | Vertical, In-line , Water cooling, four-stroke diesel engine | |
| Rated power(kw) | 75kw/60KW | |
| Rated speed(r/min) | 2400 | |
| Transmission system | Model of torque converter | YJ280 |
| pattern | 3 element single stage | |
| Gearbox type | Fixed-spindle power shift | |
| Gear shift | 2 gears ahead,2 gear astern | |
| Max travel speed | 24km/h | |
| Hydraulic system | Working pump | CBF25 |
| DISPLACEMENT | 25ml/r | |
| Working pressure | 16Mpa | |
| Distribution valve | DF20.2C | |
| Axle | Main reducer pattern | Arc taper gear, moderation of first grade |
| Pattern of wheel reduction | Planet gear moderation of single | |
| Steering system | Type | hydraulic steering |
| Min turning radius(mm) | 5000 | |
| Max turning angle | 35°±1 | |
| Tires | Standard tyres | 16/70-20 |
| Break system | Service brake type | Air assisted oil disc on four wheel |
| Parking brake type | Soft axle control, outside bunch drum type |
1.Equipped with Dongfeng Cummins ,Weichai,Luotuo,Huafeng engine
2. Strengthened and reliable transmission, drive axle
3. Optimized and choose the best quality Hydraulic component which increase the productivity ,sealing reliability
4. Articulated frame with box structure
5. Option attachment: wooden fork, pipe/pallet fork, grass fork, rock bucket, bigger bucket, long arm etc
