China Qingzhou SZM New Design Front End Loader 928 Wheel Loader With CUMMINS Engine 92kw DEUTZ Engine Joystick Quick Hitch

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Brand Name:

SZM

Model Number:

928

Qingzhou Shanzhuang Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name SZM

Model Number 928

Place of Origin Shandong, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) (Long * Breadth * High) 5980*2080*2850

Rated Load 2000kg

Certification CE

Specification	overall weight(kg)	5700
	L×W×H(mm)	5980×2080×2850
	rated bucket capacity(m3)	1.3
	Rated load(kg)	2000
	Maximum dump height (mm)	2850
	Wheelbase	2480mm
	thread	1670mm
	Max breakout force	70KN
	Total time	11.3s
	Bucket indicator	Yes
Engine	Model	Cummins4BT3.9-C100
	optional	YTR4108G92
	Type	Vertical, In-line , Water cooling, four-stroke diesel engine
	Rated power(kw)	75kw/60KW
	Rated speed(r/min)	2400
Transmission system	Model of torque converter	YJ280
	pattern	3 element single stage
	Gearbox type	Fixed-spindle power shift
	Gear shift	2 gears ahead,2 gear astern
	Max travel speed	24km/h
Hydraulic system	Working pump	CBF25
	DISPLACEMENT	25ml/r
	Working pressure	16Mpa
	Distribution valve	DF20.2C
Axle	Main reducer pattern	Arc taper gear, moderation of first grade
Axle	Pattern of wheel reduction	Planet gear moderation of single
Steering system	Type	hydraulic steering
	Min turning radius(mm)	5000
	Max turning angle	35°±1
Tires	Standard tyres	16/70-20
Break system	Service brake type	Air assisted oil disc on four wheel
Break system	Parking brake type	Soft axle control, outside bunch drum type
