Press for linen and cotton blended fabric large format Rotary sublimation roll heat press
Kindly note that as a big factory in China with a strict quality control system,5 engineers and 15+ years experience,we can promise you the quality and provide some professional guides to you if you need.
Specifications
1.CE approved
2.Air operated
3.Automatically correct blanket edge and belt
4.Explosion-proof
5.Automatically shut down
Technical parameters(customised sizes are accepted)
Roller width |
Roller diameter |
Voltage |
Power |
Temp.range |
Speed |
Weight |
Packing size |
1.2m |
420mm |
220V/380V |
22KW |
0-390°C |
1.5-2m/min |
1000KG |
215*145*174cm |
1.7m |
420mm |
220V/380V |
30KW |
0-390°C |
1.5-2m/min |
1800KG |
263*139*160cm |
2.0m |
420mm |
220V/380V |
35KW |
0-390°C |
1.5-2m/min |
2100KG |
290*145*170cm |
1.2m |
600mm |
220V/380V |
30KW |
0-390°C |
2-3m/min |
1800KG |
243*167*171cm |
1.7m |
600mm |
220V/380V |
38KW |
0-390°C |
2-3m/min |
2300KG |
263*167*171cm |
2.0m |
600mm |
220V/380V |
45KW |
0-390°C |
2-3m/min |
2700KG |
288*167*171cm |
Feature
1. The automatically shut down function provides for saving labor and time to wait for the machine cools down to close it and can avoid the blanket to burn out.
2. With a large master and automatically seperate the blanket function to ensure the blanket back far away from the roller drums to prevent from high temperature to destroy the blanket.
3. The oil temperature heating technology circulates the thermal conductivity of liquid and averagely heating to avoid explosion for ensuring the safety of all workers.
4. The unique function of automatically correct blanket edge and automatically correct the belt which controlled by the motors allows for much more accurate positioning than the anothers which controlled by the hydraulic or pneumatic system.
5. It is excellent for applying transfer to piece, roll fabric and ribbon of all types to get a faster production,(bigger roller diameter, faster speed);The 800mm diameter roller can transfer 240-300m/h under the normal working speed.It can also be used for fusing.
6. With power-off protection function, blanket and roller can be individually separated.
7. Chrome plating in the roller, it is wear resistant, anti-sticking and transfer excellent.
8. Employed the air shafts to keep the sublimation paper always flat or smooth.
9.Macine with a device of adjusting the power for saving electricity cost.
More details
Packing
Usually the small heat presses excluding the pneumatic heat presses will be packaged by carton cases.The large heat presses and printers will be packaged by wooden cases.
Delivery the machine by Train/Sea way/Air/international express
We will recommend the cheaper and more economic way for you.You can also advise us your need.
1. Comprehensive service
BEFORE: We would like to recommend the machine to you according to the function you need.
AT: Find out the most cost-saving and convenient shipping way for you.
AFTER: 1) With 15 years experience, we can provide some professional guides to you if you need.
2) The technical support on line in time can be provided with the help of our 5 engineers and several electricians.
3) Engineer available to service machinery overseas.
4) You can dispatch your workers to our factory and our engineers will train them for you.
2. Quality is our culture.
1) As a big factory in China with a strict quality control system, we can assure you of the quality.We only offer high quality products.
2) We are certified to CE.
3. Competitive price
We think our machines will give you an edge over your competitors.
4. Safety
With us your business will be in safe, your money will be in safe.
Press for linen and cotton blended fabric large format Rotary sublimation roll heat press
With 15-year experience, Guangzhou Jiangchuan Printing Equipment Co., Ltd is one of the most professional manufacturers in heat press machine, heat transfer machine, and sublimation equipment and so on.
Jiangchuan always devotes to enhance the function of their machine, depends on customers’ feedback and market requirement .At the beginning of 2001 , Jiangchuan started to produce flat heat press ; since 2005 developed first roller heat press machine; since 2012 ,Jiangchuan developed 3d heat press machine; since 2016 , Jiangchuan also promotes their newest roller heat press machine model.
Jiangchuan is also a biggest manufacturer in China, which is located in Guangzhou city with 30,000 square meters. Jiangchuan has 5 engineers ,120 workers , six production lines ,two sales teams , which supply professional service for domestic market and overseas market ,such as Europe, America, Southeast Asia, The Middle East ,Africa, etc.
Welcome to visit Jiangchuan at anytime.
Press for linen and cotton blended fabric large format Rotary sublimation roll heat press
Contact us or send me an inquiry now,we will get back to you soon.
It would be better if you could tell us what your real need to recommend the most suitable machine for you.
