DDW-S Series Digital Display Electronic Universal Testing Machine (Gate Type) is equipped with small displayer aside, which the whole operation is processing on, while all testing data and parameter will show on this displayer, it is adjustable in testing speed, and has function of auto stop when the specimen is broken, as well as peak value holding.
Equipment’s Main Structure:
The whole structure is formed by the upper beam, the middle beam, the lower beam and the bottom panel, with two pairs of ball screw-rod and a vertical column. The full-digital AC Servo motor drives the Reducer and the synchronic gear belt, so as to drive the two pairs of high-precision and seamless ball screw-rod, and to make the beam move up and down.
Using Scopes:
DDW-S Series Digital Display Electronic Universal Testing Machine (Gate Type) is applicable for tensile,compression and bending tests of materials with relatively small test force, such as rubber, plastic, textile, waterproofing material, cable, network wire, metal wire, metal rod, metal plate and others. With attaching tools, it can also do compression and bending tests.
Application:
The equipment is applicable to the measurement and analysis of mechanical performance not only metal, non-metal material, but also composite materials. It is widely used in aerospace, petrochemical, machinery manufacturing, wire and cable, textiles, fibers, plastics, rubber, ceramics, food, medicine packaging, plastic pipes, plastic doors and windows, geotextile, film, wood, paper, metal materials and manufacturing. According to GB, JIS, ASTM, DIN, ISO and other standards, it can automatically strike the maximum test force value breaking force value, yield strength, upper and lower yield strength, tensile strength, compressive strength, elongation, tensile modulus, flexural modulus test data etc.
- High-precision and fully-digital speed governing system and precision reducing gear are adopted to drive the precision screw rod to carry out the test, achieving the adjustment of testing speed by a large margin, as well as low noise and stable operation during the test;
- Operating mode of touch keys and real-time display on LCD digital screen the selection window for testing methods, selection window for testing parameters as well as displaying window for testing operation and testing result, how convenient and efficient!
- Achieve different speed levels of beam lifting adjustment when mounting and clamping the specimen,even fine turning, as well as function of overload protection;
- Suitable for externally connecting with optional controller;
- Various optional testing accessories, meet any of your measurement requirement.
Series Models |
DDW-S |
|||||
0.2 |
0.5 |
2 |
5 |
|||
Structural Form |
Gate Type |
|||||
Max. Testing Force (KN) |
0.2 |
0.5 |
2 |
5 |
||
Operation Mode |
Digital LCD Displayer |
|||||
Measuring Range |
2%-100% of the maximum testing force |
|||||
Relative Error on Indicated Values of Testing Force |
Better Than ±1% of the Indicated Value |
|||||
Error on Deformation Display |
±1% (Optional ±0.5%) |
|||||
Min. Force Resolution |
0.01N |
|||||
Displacement Precision |
±1% (±0.5% Optional) |
|||||
Deformation Accuracy |
Better than ±1% (±0.5% Optional) |
|||||
Speed Governing Range |
1-200mm/min |
|||||
Testing Travelling Distance |
>600 mm (can be customized according to needs) |
|||||
Testing Space Adjusting Mechanism |
AC Servo Motor, Drive by Synchronous Belt |
|||||
Carried Standard |
GB/T2611, ISO,ASTM,DIN |
|||||
Protection Function |
Overload Protection, Limit Protection |
|||||
Power Supply |
220V |
|||||
Weight (Approximate KG) |
400 |
500 |
600 |
|||
Operating Conditions |
Ambient Temperature -35°C, Humidity 20% - 80% |
|||||
Clamp Type |
Each One Piece of Standard Clamp for Tension Test and Compression Test (Optional Clamp If Needed;Special Clamp Can Also Be Customized for Customers) |
|||||
Standard Packing List:
Items |
Qty.
|
Main Unit |
1 |
Standard Double-clip Type Jig for Tension Test, Accessories for Compression Test |
One Pcs. Each |
Digital Displayer |
1 |
Spoke Type Loading Transducer |
1 |
Manual Book, Quality Certificate |
One Pcs. Each
|
Optional Clamps:
- 36 Months Quality Warranty from the day customers receive our goods;
- Offer customer video of machine installment,handle,operation if they need;
- If neccessory,we can provide on site adjustment and installment;
- Lifetime Technical support and solution offered by means of vedio,telephone call,or remote assistance via teamview;
- Free supply certain spare parts within warranty period;
- Free offer customer machine trainning in our factory,help to book hotel and air ticket in advacne;
- Arrange considerate and 100% satisfed customer entertainment for coming visitor.
Every set of our equipement will be carefully tested and double checked steps by steps before being packed and delivery,as we all know that among such fierce international competition,only 100% good quality and stable performance can finally attain the customer's trust.Hence,we will always put the equipment calibraton job in the first place while manufacturing.
