Banner Printing Sublimation Printer,factory Wholesale Big Size Water Base Printer Quality Choice

Name: Banner Printing Sublimation Printer,factory Wholesale Big Size Water Base Printer Quality Choice
Brand: Jiangchuan
Availability: InStock

FOB Price

US$ 6,300 - 7,000 / Set

1 Set(Min. Order)

Port Guangzhou Shenzhen
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Plate Type	Other, SUBLIMATION PRINTER
Place of Origin	Guangdong, China	Brand Name	Jiangchuan
Model Number	WT-1802H	Usage	Paper Printer, Other, Paper Printer, For sublimation paper and banner
Automatic Grade	Automatic	Voltage	220/110V
Gross Power	800W	Dimensions(LWH)	14529190CM
Weight	450KG	Certification	CE
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Banner printing sublimation printer,factory wholesale big size water base printer

Technical parameters

Print head	Using Double 5113 print head, including 400 nozzles/row8 lines2, the nozzles is four times than before, high output quality up to 1800 dpi.
Media max. print width	1800mm
Print Resolution/speed	(3 pass)7201800dpi 70m²/H (4 pass)7201200dpi 50m²/H (6 pass)720*1800dpi 32m²/H
Ink sort	Water Based Ink, Sublimation Ink
Ink capacity	Double 4 Color:220mlX2/color
Media Thickness	1.5mm to 8mm adjustable
Media Maximum Roll Weight	80kg
Media Sort	Sublimation Paper, PP Synthetic Paper etc.
Media Heater	Pre-print /post heater(can be controlled separately)
Media take-up Device	Strong rolling take-up device with the automatic damper(Option)
With drying system	yes( Infrared drying system)
Guide Rail	THK from Japan
Interface	USB2.0(480m/s)
RIP Software	MaintopV5.3,Photoprint,Seeget,Torpaz
Power	AC110V±10%,AC220V±10%,50/60±1HZ
Operation Environments	Temperature:20℃~35℃,Humidity:35%RH~65%RH
Dry Power	2000W
Gross Weight	840kg
Packing dimensions	14604420950MM

Banner printing sublimation printer,factory wholesale big size water base printer

Description:

1. The heater can be controlled by separately.

The heaters can be controlled by separately to head the media to be appropriate temperature to improve the absorption of ink. Front heater can reduce the drying time and speed up the efficiency of collecting paper.

2.Roll to roll device

Roll to roll device can take up the paper roll and prevent from deviation when printing long paper.

3. VSD technology

The new variable droplet technology achieves the grayscale and make the printing more delicate and accurate .Getting the perfect printing effect with VSD technology even though in high speed or low resolution cases.

4. Industrial circuit design

Using industrial circuit design to ensure the reliable and stable circuit. High-capacity automatic ink-supply system to ensure the overall stability off machines. That would be more effective.

5. Adjustable height of the print head

The height of print head can be adjusted according to the thickness of media from 1.5mm to 8mm to ensure the spray quality.

6. Continuous ink supply system

With the continuous supply system to ensure the printer can print large format and high quality images and improve the efficiency.

Banner printing sublimation printer,factory wholesale big size water base printer

Competitive Advantage:

1.Using BYHX software

It is excellent for improving the print quality and showing high definition by using the BYHX software with leading technology and stable control system.

2.High output quality

Using dual 5113 print heads,400 nozzles*8 lines*2,the nozzles is four times than before, output

quality up to 1800 dpi. The staggered arrangement of the print heads significantly improves the productivity!

3. Employs THK rails from Japan

The THK guide rails from Japan ensure nozzle movement more stable, longer life, lower noise. Meanwhile, the THK rails ensure the precision (parallelism and straightness is 0.01mm through testing).

4. Applying NSK High quality bearings

The bearings are imported from Japan. It improves the precision and service life, which can reach over 5 years.

5. Aluminum material

The unique aluminum structure is excellent for ensure the paper is flat to print the better images.

6. Leadshine brushless servo motor for the printer

Employs double leadshine brushless servo motor to get the stable and safe transmission.

Packaging & Shipping

Packing

Usually the small heat presses excluding the pneumatic heat presses will be packaged by carton cases.The large heat presses and printers will be packaged by wooden cases.

Delivery the machine by Train/Sea way/Air/international express

We will recommend the cheaper and more economic way for you.You can also advise us your need.

Banner printing sublimation printer,factory wholesale big size water base printer

Why choose us?

1. Comprehensive service

BEFORE: We would like to recommend the machine to you according to the function you need.

AT: Find out the most cost-saving and convenient shipping way for you.

AFTER: 1) With 15 years experience, we can provide some professional guides to you if you need.

2) The technical support on line in time can be provided with the help of our 5 engineers and several electricians.

3) Engineer available to service machinery overseas.

4) You can dispatch your workers to our factory and our engineers will train them for you.

2. Quality is our culture.

1) As a big factory in China with a strict quality control system, we can assure you of the quality.We only offer high quality products.

2) We are certified to CE.

3. Competitive price

We think our machines will give you an edge over your competitors.

4. Safety

With us your business will be in safe, your money will be in safe.

Banner printing sublimation printer,factory wholesale big size water base printer

Factory & Exhibition

With 15-year experience, Guangzhou Jiangchuan Printing Equipment Co., Ltd is one of the most professional manufacturers in heat press machine, heat transfer machine, and sublimation equipment and so on.

Jiangchuan always devotes to enhance the function of their machine, depends on customers’ feedback and market requirement .At the beginning of 2001 , Jiangchuan started to produce flat heat press ; since 2005 developed first roller heat press machine; since 2012 ,Jiangchuan developed 3d heat press machine; since 2016 , Jiangchuan also promotes their newest roller heat press machine model .

Jiangchuan is also a biggest manufacturer in China, which is located in Guangzhou city with 30,000 square meters. Jiangchuan has 5 engineers ,120 workers , six production lines ,two sales teams , which supply professional service for domestic market and overseas market ,such as Europe, America, Southeast Asia, The Middle East ,Africa, etc.

Welcome to visit Jiangchuan at anytime.
