Help CenterIn-Line ATC CNC Wood Working Machine
Related Products
Specifications
cnc wood working machine:1.Taiwan high precision,H30 linear guide rail
2.An chuan servo motor
3.Baoyuan control system
In-Line ATC CNC wood working machine :
- X,Y working area: 2000mm*4000mm
- Z working area: 400mm
- Table size: 2180mm*4500mm
- 5kw water cooling spindle
- Taiwan LNC control system
- In-line 8 tools changer
- Auto tool aligning system, Auto oiling
- Taiwan AMT liner guide rail
- Type3 software
- Whole cast channel steel structure
- ballscrew for Z axis, gear-wheel for X axis and Y axis
- vacuum table with 10 separately control zones
- 7.5kw vacuum pump
- Leadshine MD2278 drivers (two drivers for Y axis)
- Japan servo motors(two sets for Y axis)
- Dust collector system
- 12 cutters( φ6, φ12.7), 3 collets
- Precision: 0.005mm
- Reposition accuracy: 0.05mm
- Max feeding: >35m/min
- Command: G* code*.uoo*.mmg*.plt
- Power: AC380V/50HZ
Technical Parameters:
Model |
HDM40H |
XY working area |
2000x4000mm |
Z working area |
>200mm |
Table size |
2100x4500mm |
Max travel speed |
8m-30m/min |
Processor |
DSP/Frequency 100MHz |
Interface |
PCI card |
Command |
G code*.u00*.mmg*.plt |
Surroundings for software |
Windows98/2000/xp |
Power(not include the spindle) |
1500-2000W |
Working voltage |
AC220V/50Hz |
spindle power rate |
5kw water cooling |
spindle rotating speed |
24000rpm/min |
Drive motor |
Servo |
Applicable industry and material
1. Furniture: wooden doors, cabinets, plate, office and wood furniture, tables, chair, doors and windows.
2. The wood products: voice box, game cabinets, computer tables, sewing machines table, instruments.
3. Plate processing: insulation part, plastic chemical components, PCB, inner body of car, bowling tracks, stairs, anti-Bate board, epoxy resin, ABS, PP, PE and other carbon mixed compounds.
4. Decorate industry: Acrylic, PVC, MDF, artificial stone, organic glass, plastic and soft metals such as copper, aluminum plate engraving and milling process.
the working samples:
Our services:
1.The processing demo video and E-catalogue will be mailed as your request.
2.One year free warranty under normal using.
3.Free training to guarrantee you can operate machine correctly.
In addition, we have woodworking engraver, relief engraver, cylinder craft wood engraver, special mould engraver, stone engraver, advertising machines, laser engraving/cutting machines and so on.
we can make carving machines with all specifications to meet user's requirements.
Thank you for your visiting the product of HongDa BoKe!
Your satisfaction is our pursuit.
