Help CenterCNC Router for Export
Related Products
Specifications
CNC router for export:long lifte time,high precison
Imported square orbit and ballscrew.
Vacuum table with 6 vacuum zones
CNC router for export
Model |
M25-X |
Option |
XY working area |
1300X2500mm |
<2000mm×4000mm |
Z working area |
200mm |
<450mm |
Table size |
1480x3000mm |
|
Max feeding |
>35m/min |
|
Work-holding |
By suction |
|
Processor |
DSP/Frequency 100MHz |
|
Interface |
USB |
|
Command |
G code*.u00*.mmg*.plt |
|
Surroundings for software |
DSP |
|
Power(not include the spindle) |
1840W |
|
Working voltage |
380V/50Hz |
|
spindle power rate |
4.5KW(Italy air cooling) |
3/6KW |
spindle rotating speed |
0-18000rmp/min |
|
Drive motor |
Servo |
Servo |
CNC router for export Features(part):
One: Adopt imported square orbit, double slippers, bearing heavy, working steadily, high precision, and long life, import ballscrew, high precision for cutting.
Two: Adopting advanced DSP system, operated with the handle, convenient operation, humanization design. Unique intelligent budget principle, fully develops the potential of the motor and lead to high processing speed, the synchronization of curves and straight lines, smoother curves.
Three: Adopt high speed motor and drivers,and two motors for y axis. Max speed is 35M/MIN. Auto Aligning System with air cooling spindle highly upgrade the processing speed.
Four: Well compatibility: CAD/DAM designing software e.g.type3/artCAM/Castmate/Wentai etc
In addition, we have woodworking engraver, relief engraver, cylinder craft wood engraver, special mould engraver, stone engraver, advertising machines, laser engraving/cutting machines and so on.
we can make carving machines with all specifications to meet users.
