5000kg.3m3 Bucket Capacity Wheel Loader With ce for Saudi Arabia

5000kg.3m3 Bucket Capacity Wheel Loader With ce for Saudi Arabia thumbnail-1
5000kg.3m3 Bucket Capacity Wheel Loader With ce for Saudi Arabia thumbnail-2
5000kg.3m3 Bucket Capacity Wheel Loader With ce for Saudi Arabia thumbnail-3
5000kg.3m3 Bucket Capacity Wheel Loader With ce for Saudi Arabia thumbnail-4
5000kg.3m3 Bucket Capacity Wheel Loader With ce for Saudi Arabia thumbnail-5
5000kg.3m3 Bucket Capacity Wheel Loader With ce for Saudi Arabia thumbnail-6
5000kg.3m3 Bucket Capacity Wheel Loader With ce for Saudi Arabia photo-1
5000kg.3m3 Bucket Capacity Wheel Loader With ce for Saudi Arabia photo-2
5000kg.3m3 Bucket Capacity Wheel Loader With ce for Saudi Arabia photo-3
5000kg.3m3 Bucket Capacity Wheel Loader With ce for Saudi Arabia photo-4
5000kg.3m3 Bucket Capacity Wheel Loader With ce for Saudi Arabia photo-5
5000kg.3m3 Bucket Capacity Wheel Loader With ce for Saudi Arabia photo-6
US$ 25,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
szm
Model Number:
956
Contact Supplier Request Quote Chat Now
Qingzhou Shanzhuang Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name szm
Model Number 956
Place of Origin Shandong, China
Type Front Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 7836*3010*3300mm
Rated Load 5000kg

5000kg.3m3 bucket capacity wheel loader with ce for saudi arabia5000kg.3m3 bucket capacity wheel loader with ce for saudi arabia5000kg.3m3 bucket capacity wheel loader with ce for saudi arabia5000kg.3m3 bucket capacity wheel loader with ce for saudi arabia5000kg.3m3 bucket capacity wheel loader with ce for saudi arabia5000kg.3m3 bucket capacity wheel loader with ce for saudi arabiaWeichai Steyr diesel engine offers great power and torque reserve and has lower fuel consumption and less noise. The engine has relable performance and is equipped with the standard 2-stage air filter adaptable to the more dusted work sites.
The LG50 power shift planetary transmission is compact and has more durable gears.the new tyepe of vibration damper is used to improve shock absorbing effects.
The selected model is Lingong 5-ton reinforced drive axle featuring outstanding performance and mature technologies. This drive axle has more load bearing capability and higher reliability.
The whole piece of carriage structure has beem through finite element optimization design and 200,000 times of fatigue intensified test. Both the front and rear carriages use the plate-style structure and thus the gravity is well-distributed. It has strong loading capability and rigidity as well as good stability.





 Spring suspended and well-sealed cabin have good sound insulation and wide visibility.
Short wheel base chassis improves steering flexibility and operation efficiency.
Heavy load driving system assures long-time work in intensive operating environment.
Anti-abrasion integral cutting edge with teeth and adapters prolong the life of bucket.
Double-turbo hydraulic torque-converter together with dynamic planet-type gear box enable a wide and high efficient range and facilitate the gear shifting.
Four-wheel, dual-line and pliers disc braking system ensures safer and more reliable operation.
Optional attachments:Coal bucket, Rock bucket, High dumping, side dumping, Cummins or Cat engine, ZF transmission, Joystick, Air-conditioner, Centralized lubrication system.

Optional engine: Cummins 6CTA8.3-C215 160kw/2200r/min                  CAT C6121 162kw/2200r/min                  Shangchai D6114 162kw/2200r/min                  Shangchai D9 160kw/2200r/min                  Weichai WD10G220 162kw/2200r/min                  Hanfa Steyr WD61561AG26 162kw/2200r/min



Main technical performances and parameters



Engine

Rated power

162kw
Overall dimensions

Overall length

7310mm

Overall width

2840mm

Overall height

3220mm

Bucket width

2990mm

Dumping height

3100mm

Dumping reach

1290mm

Specification of tires

23.5-25

Wheel base

2760mm

Tire width

2240mm

Performance parameters of entire machine

Operating weight

≤ 16100KGS

Bucket capacity

3.0m3

Rated loading capacity

5000KGS

Max. Climbing Gradient

28o

Turning angle

35o±1o

Turning radius

6650mm

Max.breakout force

145kN

Max. torque

745.3N.m

Rated speed

2200r/min

Engine model

WD10G220E11

Lifting time

≤ 6.8s

Total cylinder time

≤ 12.55s

Travel speed

 Forward gear I

0-11.5km/h

 Forward gear II

0-38km/h

Reverse gear I

0-16km/h

Details Info for Brand New Reliable Zl50 Wheel Loader LT953:

1.Electro-hydraulically controlled transmission with automatic shift and pilot control for implement hydraulic system are adopted.
2.Hydraulic steering system makes the turning easier
3.wheel loader frames are simple in structure and accessible in maintenance
4.Front and rear frames use long span connecting structure for reducing the stress in hitch pin
5.Anti-abrasion integral cutting edge with teeth and adapters, prolong the life of bucket.
6.Long wheelbase and centrally symmetrical structure make the front and rear tracks superposed on each other for extending the life of tire.
7.Optional implements for wheel loader LT953: High dump, Coal bucket, Rock bucket, Air-conditioner, Cummins engine, Centralized lubrication system

SPECIFICATIONS
Rated capacity 3m3
Rated   weight 5000Kg
Operating weight 16000Kg
Performance of bucket being set level Yes
Static tilting load at full steering position 98KN
Max. breakout force 172.6KN
Max. drawbar pull 151.9KN
Max. grade ability 30°
Total of three time:lifting,dumping, lowering 11.3s
Max.dump height 3098mm
Max.dump reach 1198mm
Min. ground clearance 450mm
Wheel base 3200mm
Overall dimensions(length*width*height) 7836*3010*3300mm
Pattern Inline,water cooled, dir.inject,fourstrokees
Cylinder-bore*stroke 6-126*130
Max.torsion 779Nm
Model of engine STEYR WD10G220E21
Rated power 220hp
Min.fuel consuming rate 214g/kw.h
Specified rotational speed 2200r/min
Model of torque device YJ375
Pattern 3-element,single stage
Number of great shift 4 forward,4 revers
Max.travel speed 38km/h
Main reducer type Spiral bevel gear, moderationof first stage
Pattern of wheelside moderation Single stage planetary
Type size 23.5-25
Front type pressure 392KPa
Rear type pressure 343KPa
Pattern Articulated and hydraulic steering,load sensing meets
Steering angle(each direction) 35°C±1
Min.turning radius(outside of bucket) 7268mm
Valve distributing working DF32·2C
Working pumps CBG3100
Brake system Air assisted oil type four wheel brake
Parking  brake Air cutting control inner expand hoof
Fuel capacity 320L
Pressure of working hydraulic system 160kfg/cm2
