XHR-150M Motorized Plastic Rockwell Hardness Tester is a kind of electrical type of plastic hardness tester used to test the hardness of plastic,hard rubber,synthetic resin,composite materials,various friction materials,soft metal,and non-metallic materials.
Using Scopes:
- Rockwell Hardness Testing of Ferrous Metal,Non-ferrous Metalt and Non-metallic Material.
Rockwell Hardness Range:
Rockwell hardness scale |
Hardness symbol
|
Indenter type |
Initial l force Fo (kg) |
main force F1 (kg) |
Total force F(KG) |
Constant |
Scope of application |
Examples of application |
A |
HRA |
diamond cone indenter |
10 |
50 |
60 |
100 |
20-88HRA |
Hard metal and hard alloy |
B |
HRB |
1.5875mmball indenter |
10 |
90 |
100 |
130 |
20-100HRB |
Nonferrous metal and soft metal |
C |
HRC |
diamond cone indenter |
10 |
140 |
150 |
100 |
20-70HRC |
heat treatment steel |
D |
HRD |
diamond cone indenter |
10 |
90 |
100 |
100 |
40-77HRD |
Surface hardened steel |
F |
HRF |
1.5875mmball indenter |
10 |
50 |
60 |
130 |
60-100HRF |
Nonferrous metal |
G |
HRG |
1.5875mmball indenter |
10 |
140 |
150 |
130 |
30-94HRG |
iron, copper nickel, zinc alloy |
- A scale: It is suitable for testing the metal more than 70HRC, such as tungsten carbide, hard alloy as well as the hard sheet material and the hardening material on the surface layer.
- B scale: It is suitable for testing non-ferrous metals and alloys, annealing steel or soft or medium hardness of materials.
- C scale: It is suitable for testing the carbon steel, tool steel and alloy steel.
- Automatically loading,dwell,unloading,without man-made error,easy operation and durable test;
- High testing efficiency,with high accuracy hydraulic buffer;
- Durable and reliable loading,support adjustable loading speed;
- Direct dial readings,with scales of HRE,HRL,HRM,HRR and other optional scales;
- Quality certified with GB/T230.1/.2 Natioanal Standard,ISO 6508-2,ASTM E18.
Model |
XHR-150M |
Initial Testing Force |
10kgf(98.07N) |
| Hardness Resolution | 0.5HR |
Testing Force |
60kgf(588N) 100kgf(980N) 150kgf(1471N) |
Rockwell Scale |
HRA HRB HRC HRD HRE HRF HRG HRH HRK |
Testing Range |
HRA:20-88 HRB:20-100 HRC:20-70 HRD:40-77 HRF:60-100 HRG:30-94 HRH:80-100 HRK:40-100 |
DataDisplay mode |
Dial |
| Operate Mode | Motorized |
Carried Standard |
GB/T230.1/.2 Natioanal Standard,ISO 6508-2,ASTM E18 |
Max Height of Specimens |
200mm |
Max depth of specimens |
135mm |
| Power Supply | 220V,50/60Hz |
Dimension (cm) |
61*40*80(L*W*H) |
Packing Weight |
70KG |
Standard Packing List:
Items |
Qty |
Items |
Qty |
Diamond Rockwell Indentor |
1 |
Dia.1/16'' ball indentor |
1 |
Standard Superficial Rockwell Hardness Block |
4 |
Big,Medium and V shaped Testing Platform |
1 each |
Weight(A,B,C) |
1 each |
Dustproof Cover |
1 |
User’s Manual Book |
1 |
Quality Certificate |
1 |
Optional Accessories for Rockwell Hardness Tester:
Rockwell Hardness Block:
Rockwell Hardness Indenter(Good Quality Diamond):
Every set of our equipement will be carefully tested and double checked steps by steps before being packed and delivery,as we all know that among such fierce international competition,only 100% good quality and stable performance can finally attain the customer's trust.Hence,we will always put the equipment calibraton job in the first place while manufacturing.
