Home > Instruments & Meters > Physical Measuring Meter > Hardness Tester > DTEC HBS-3000 Digital Brinell Hardness Tester,built-in Printer Full Automatic Testing,durable and Reliable Performance,CE,ASTM.

DTEC HBS-3000 Digital Brinell Hardness Tester,built-in Printer Full Automatic Testing,durable and Reliable Performance,CE,ASTM.

Name: DTEC HBS-3000 Digital Brinell Hardness Tester,built-in Printer Full Automatic Testing,durable and Reliable Performance,CE,ASTM.
Brand: DTEC
SKU: 121553903

DTEC HBS-3000 Digital Brinell Hardness Tester,built-in Printer Full Automatic Testing,durable and Reliable Performance,CE,ASTM. thumbnail-1

DTEC HBS-3000 Digital Brinell Hardness Tester,built-in Printer Full Automatic Testing,durable and Reliable Performance,CE,ASTM. thumbnail-2

DTEC HBS-3000 Digital Brinell Hardness Tester,built-in Printer Full Automatic Testing,durable and Reliable Performance,CE,ASTM. thumbnail-3

DTEC HBS-3000 Digital Brinell Hardness Tester,built-in Printer Full Automatic Testing,durable and Reliable Performance,CE,ASTM. thumbnail-4

DTEC HBS-3000 Digital Brinell Hardness Tester,built-in Printer Full Automatic Testing,durable and Reliable Performance,CE,ASTM. photo-1

DTEC HBS-3000 Digital Brinell Hardness Tester,built-in Printer Full Automatic Testing,durable and Reliable Performance,CE,ASTM. photo-2

DTEC HBS-3000 Digital Brinell Hardness Tester,built-in Printer Full Automatic Testing,durable and Reliable Performance,CE,ASTM. photo-3

DTEC HBS-3000 Digital Brinell Hardness Tester,built-in Printer Full Automatic Testing,durable and Reliable Performance,CE,ASTM. photo-4

US$ 3,200 - 4,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Beijing, China

Brand Name:

DTEC

Model Number:

HBS-3000

Contact Supplier Request Quote Chat Now

Beijing Deity Testing Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Beijing Air Port;Tianjin Sea Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Beijing, China

Brand Name DTEC

Model Number HBS-3000

Product Description

HBS-3000 Digital Brinell Hardness Tester equips with large digital LCD high resolution display sreen as well as buit-in printer and full automatic operation control system; additionally,it adopts full automatic close-loop transducer control system, with 10 levels testing force and 14 kinds of testing scales; what's more, this model employs selectable electron loading and weight loading,the user can choose either of them according to measurement requirement; it is mainly used to test brinell hardness of cast, annealed steel, normalized steel, non-metallic materials and soft alloy.

With wide application range, it is not only applicable to the precision measurement of paralleled surface, but also can reliably and durably be suitable in curve measurement.

Application Areas:
Metallurgy, metrology, building materials, research institutes, hardening shops, stainless steel, automotive, railway, energy, steel, aviation, roller plants, tube rolling mills, foundries etc.

Workpieces Scopes:
Non-hardened steel, cast iron, annealed steel, normalized steel, non-metallic metals, alloys bearing ,plates, sheets, motor blocks, rails, rings, bars, tires, wheels, castings etc.

DTEC Advantages

Large digital LCD high resolution displaying screen, menu smart tips and flexible and convenient operation functions;

Full automatic close-loop transducer control system;

Built-in printer, equips with RS-232 data port, suitable to connect to PC;

10 levels testing force and 14 kinds of testing scales;

Strong structure, good rigidity, high testing accuracy and efficiency, durable and reliable performance;

Employs electron loading instead of weight loading, auto-protection against overload and over-bit;

Full automation testing course, without man-made error;

Suitable to install with optional CCD brinell indentation image processing system device (see picture below);

The machine accuracy is in line with GB/T231.2, ISO 6506-2 and American Standard ASTM E10.

Specification

Model	HBS-3000
Testing Range	8-650HBW
Hardness Scales	HBW2.5/62.5 HBW10/100 HBW5/125 HBW2.5/187.5 HBW10/250 HBW10/500 HBW5/750 HBW10/1000 HBW10/1500 HBW10/3000
Testing Force	62.5kgf(612.9N),100kgf(980.7N),125kgf(1226N),187.5kgf(1838.8N),250kgf(2415.8N), 500kgf (4903N), 750kgf(7355,3N),1000kgf(9807N), 1500kgf (14710N), 3000kgf(29421N)
Displaying Mode	Large LCD display
Microscope Amplification	20x
Carried Standard	GB/T231.2, ISO 6506-2,ASTM E10
Specimens Max. Height	200mm
Max.Specimen Depth	135mm
Power Supply	AC220V,50/60Hz
Dimension(cm)	7543125cm
Packing Weight	150KG

Packing List & Accs

Standard Packing Accessories:

Items	Qty.	Items	Qty.
20x Microscope	1 set	Φ2.5,Φ5,Φ10 alloy ball indentor	1 each
Standard Brinell Block	2	Big,Medium,V type Testing Platform	1 each
Power Cable	1	Quality Certificate,Manual Book	1 each

Optional Accessories:

Brinell Hardness Block:

Brinell Indenter:

Portable Reading Microscope:

Two Models:JC-10(20X),JC-5(40X)

Packaging & Shipping

Every set of our equipement will be carefully tested and double checked steps by steps before being packed and delivery,as we all know that among such fierce international competition,only 100% good quality and stable performance can finally attain the customer's trust.Hence,we will always put the equipment calibraton job in the first place while manufacturing.
