Marble And Granite CNC Router engraving machine
- 100 Set / Sets per Month
- Qingdao
- Credit Card
- Granite Marble CNC Milling and Cutting Bridge Saw Machine Infrared Quartz 5 Axis Granite Tile Back Splash Machine Cnc
- Bridge saw type cnc stone cutting machine for marble granite quartz kitchen countertop
- automatic stone cutting machine/cnc granite cutting machinery Bridge Saw for stone countertop
- 2024 new CNC four-axis bridge stone cutting machine for Artificial granite marble slabs
- 5 axis 45 degree chamfering granite quartz bridge saw stone carving cutting machine
- Integrated Mobile Bridge Saw Adopts Microcomputer Control Used Marble Simple Stone Granite Infrared 5 Axis Cnc Cutting Machine
Product Details
Condition: | New | Type: | Stone Engraving Machine | Use: | Marble |
Production Capacity: | 100sets/month | Place of Origin: | Shandong, China | Brand Name: | HONGDA BOKE, Hongda boke |
Model Number: | HD-1218, HD-1218 | Voltage: | AC380V/50Hz | Power(W): | 4.5KW |
Dimension(L*W*H): | 1200*1800mm | Weight: | 2000KG | Certification: | CE ISO |
Warranty: | 12 Months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Marble And Granite CNC Router engraving machine
Technical Parameters:
Model | HD1218 |
Table size | 1200x2000mm |
XY working area | 1380 x 2300mm |
Z working area | 300mm |
Max running speed | 20m/min |
Max engraving speed | 5m/min |
Resolutions | 0.005mm |
Max feeding heigh | 300mm |
Spindle power | 3-8KW |
Spindle rotating speed | 0-24000rpm/min |
Drive motor | stepper |
Specifications:
*Adopt Taiwan linear guide rail. The bearing of the lead guide rail is face to face, the long time use precision is high.
*German double nuts automatic ball screw.
*High speed driver, high speed ,high power
*No dust oiling structure, guarantee the long term running of the mechanical aspect.
*Break point and break knife continue engraving function, can engrave at any place as you like.
*The compatibility is high, CAD/CAM software such as Type3/artcam/castmate/proe/corelerow/Artcut.
*High power frequency changing water cooled spindle, can process hard materials efficiently.
Standard configurations:
1. Whole cast iron structure, Three axis imported square orbits. Imported ballscrow, three axies dust proof, water proof
2. 4.5kw imported bearing water cooling spindle
3. Taiwan made inverters, fully shielded, uneasy distorted cable.
4. U flash disk, DSP control system. Wentai software, Type 3 software
5. 20 cutters( 3.175mm. 4mm. 6mm),3 collets
Applicabel Materials:
Marble, granite, China black, bluestone, jade, ceramic, crystal, glass, plastic, plexiglass, PVC board, bamboo, aluminum pannels, mental etc materials.
Applicable Industry:
Stone, sombstone processing, advertising, decoration, crafts etc. 3D, 2D carving, three dimensional relief, cutting, drilling, industries.
Packing Details:Wooden case.
Delivery Time:15 working days after receiving payment.
Shipping picture
1.18 months quality guaranty, the machine with main parts(excluding the consumables)
shall be changed free of charge if there is any problem during the warranty period.
2.Lifetime maintenance free of charge.
3.Free training course at our plant.
4.We will provide the consumable parts at an agency price when you need replacement.
5.24 hours on line service each day, free technical support.
6.Machine has been adjusted before delivery.
7.Our staff can be sent to your company to install or adjust if necessary.
Hongda Boke is a professional CNC router manufacturer. We have many computerized numerical patents. Our company is devoted to the research and development of caving CAD/CAM technology and CNC technology and have obtained remarkable achievement in the design of precise caving machine as well as artistic carving.
We have realized industrialization of CNC technology. Our routers sell well in many countries and regions in Europe and the Americas, which have established a leading position in the carving machine field.
Our products have covered woodworking industry, advertising decoration, making label industry as well as craft and gift field. Our products are famous for low price, good quality and good after sales service. Our market has been expanding. We are still trying our
best to produce innovative products and provide better service for our customer.
Our factory
Exhibition show
Where come to Hongda Boke!
Wish you have a good day!
Q1.What control system it use ?
A: Ncstudio control system or DSP controlling system.
Q2.Which kind of machine is more suitable for me?
A:It is according to the material and processing thickness and the working area .
Q3.How to support me if i don't know how to use it?
A:free training by online,tel and mail or study in our factory.
Q4.How to transport?
A:By sea .
