Help CenterGranite Engraving Machine
Related Products
Specifications
Granite Engraving MachineHigh precision
High speed
Process hard materials
Low price
Granite Engraving Machine Technical Parameters:
1.X Y Z Working area:900*1800*200mm
2.Highest running speed:5m/min
3.Highest engraving speed:3m/min
4.Max feeding height:150mm
5.Rotate speed of the spindle 0-24000rpm/min
6.Working model:Stepper
Granite Engraving Machine Features:
A.Germany double nuts automatic ball screw.
B. high speed, high power. NO dust oiling structure.
C. Break point and break knife continue engraving function, can engraving at any as you like.
D. Well compatibility,Type3/Artcam/castmat/wentai/software.
E. The bearing of the lead guide rail is face to face, the long time use precision is high.
Granite Engraving Machine Configuration:
1. Whole cast iron structure, Bearing heavy, three axis imported square orbits,
2. Imported ball screw, three axis dust proof, water proof,
3.4kw imported bearing water cooling spindle
4.Taiwan made inverters, fully shielded, uneasy distorted cable,
5.U flash disk DSP control system, Wentai software, type3 software
sample:
Applied area: The machine mainly used in the engraving of hard materials such as solid wood, marble, granite, glass, stone tombstone etc.
In addition, we have woodworking engraver, relief engraver, cylinder craft wood engraver, special mould engraver, stone engraver, advertising machines, laser engraving/cutting machines and so on.
we can make carving machines with all specifications to meet users.
