Help CenterSmall Cylinder CNC Engraving Machine for Wood(HD-1200Y)
Related Products
-
Cnc Router Woodworking Engraver MachineUS$ 1 - 1MOQ: 1 Set -
4-Axis Wood CNC Router Furniture Making MachineUS$ 1 - 1MOQ: 1 Set
-
Craft Woodworking MachineNegotiableMOQ: 1 Set
-
Wood Craft EngraverNegotiableMOQ: 1 Set
-
Wood Relief Engraving Machine(For Wood,acrylic,advertisement,relief,stone,organic Galss,double-color Board,copper,aluminum,)NegotiableMOQ: 1 Set
Specifications
Cylinder CNC Engraving Machine for Wood:Two-way position rail high precision.Water-cool main axle with 2.2kw frequency convers
Small Cylinder cnc engraving machine for wood (HD-1200Y)
Technical parameter:
Model |
HD-1200Y |
XY working area |
1200x200mm |
Z working area |
200mm |
Table size |
1710x530mm |
Max feeding |
4m-5.5m/min |
Work-holding |
2m-3m/min |
Resolution |
0.005mm |
Interface |
USB |
Command |
G code*.u00*.mmg*.plt |
Surroundings for software |
Windows98/2000/xp |
Power(not include the spindle) |
500W |
Working voltage |
AC220V/50Hz |
spindle power rate |
2.2KW |
spindle rotating speed |
0-24000rpm/min |
Drive motor |
steper |
Features:
1. Servo rotation axis, high efficiency.
2. four axis control system with industrial PC , working steadily..
3. It can be used not for not only cylinder engraving, but also flat engraving. .
1.Whole steel structure, all round orbits, ball screw,
2. NC studio control system, Wentai Software Type3 Software,
3. 2.2Kw water cooling spindle,
4.20 cutters (φ3.175, φ4, φ6), 3 collets
1.Whole steel structure, all round orbits, ball screw,
2. NC studio control system, Wentai Software Type3 Software,
3. 2.2Kw water cooling spindle,
4.20 cutters (φ3.175, φ4, φ6), 3 collets
how to order?
how to contact with us?
