Large Format Multifunctional Roller Transfer Printing Machine Roll to Roll Heat Sublimation

Large Format Multifunctional Roller Transfer Printing Machine Roll to Roll Heat Sublimation photo-1
Large Format Multifunctional Roller Transfer Printing Machine Roll to Roll Heat Sublimation photo-2
Large Format Multifunctional Roller Transfer Printing Machine Roll to Roll Heat Sublimation photo-3
US$ 6,500 - 13,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Plate Type Flatbed Printer
Place of Origin Guangdong, China
Brand Name Jiangchuan
Model Number JC-26B
Usage Cloths Printer
Automatic Grade Automatic
Voltage 220/380V
Gross Power 45KW
Dimensions(L*W*H) 288*167*171
Weight 2700KG
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Large format multifunctional roller transfer printing machine roll to roll heat sublimation





Technical parameters:



Roller width

Roller diameter

Voltage

Power

Temp.range

Speed

Weight

Packing size

1.2m

420mm

220V/380V

22KW

0-390°C

1.5-2m/min

1000KG

215*145*174cm

1.7m

420mm

220V/380V

30KW

0-390°C

1.5-2m/min

1800KG

263*139*160cm

2.0m

420mm

220V/380V

35KW

       0-390°C

1.5-2m/min

2100KG

290*145*170cm

1.2m

600mm

220V/380V

30KW

       0-390°C

2-3m/min

1800KG

243*167*171cm

1.7m

600mm

220V/380V

38KW

0-390°C

2-3m/min

2300KG

263*167*171cm

2.0m

600mm

220V/380V

45KW

0-390°C

2-3m/min

2700KG

288*167*171cm






Features:



1. The automatically shut down function provides for saving labor and time to wait for the machine cools down to close it and can avoid the blanket to burn out.



2. With a large master to ensure the blanket back far away from the roller drums to prevent from high temperature to destroy the blanket.



3. The oil temperature heating technology circulates the thermal conductivity of liquid and averagely heating to avoid explosion.



4. The unique function of automatically correct blanket edge allows for more accurate positioning.



5. It is excellent for applying transfer to piece, roll fabric and ribbon of all types to get a faster production,(bigger roller diameter, faster speed);The 800mm diameter roller can transfer 240-300m/h. It can also be used for fusing.



6. With power-off protection function, blanket and roller can be individually separated.



7. Chrome plating in the roller, it is wear resistant, anti-sticking and transfer excellent.



8. Employed the air shafts to keep the sublimation paper always flat.



Machine images:



Large format multifunctional roller transfer printing machine roll to roll heat sublimationLarge format multifunctional roller transfer printing machine roll to roll heat sublimationLarge format multifunctional roller transfer printing machine roll to roll heat sublimationLarge format multifunctional roller transfer printing machine roll to roll heat sublimationLarge format multifunctional roller transfer printing machine roll to roll heat sublimation



Company Information

Large format multifunctional roller transfer printing machine roll to roll heat sublimation

With 15-year experience, Guangzhou Jiangchuan Printing Equipment Co., Ltd is one of the most professional manufacturers in heat press machine, heat transfer machine, and sublimation equipment and so on.

Jiangchuan always devotes  to enhance the function of their machine, depends on customers’ feedback and market requirement .At the beginning of 2001 , Jiangchuan started to produce  flat heat press ; since 2005  developed  first roller heat press machine; since 2012 ,Jiangchuan developed 3d heat press machine; since 2016 , Jiangchuan also promotes  their newest roller heat press machine model .

Jiangchuan is also a biggest manufacturer in China, which is located in Guangzhou city with 30,000 square meters. Jiangchuan has  5 engineers ,120 workers ,  six production lines ,two sales teams , which supply professional  service for  domestic market and overseas market ,such as Europe, America, Southeast Asia, The Middle East ,Africa, etc.



Welcome to visit Jiangchuan at anytime.

Large format multifunctional roller transfer printing machine roll to roll heat sublimation

Our Services

Warranty:

1.  One-year warranty on machines and parts.

2.  We provide overseas advanced technology support.

3.  All our Heat Press/Heat Transfer Machines are CE, SGS, Alibaba approved.



Payment:

 L/C, T/T, Western Union, Paypal, Cash, Secure Payment are accepted.



Quality Control:

All our heat presses are strictly tested under the following procedures before shipping.

1) Turn on the machine, let it heating up to 220 degree Celsius;

2) Use black transfer paper test print fabrics.

Large format multifunctional roller transfer printing machine roll to roll heat sublimation

FAQ

Q1: What’s your product range?

1. Semi-automatic, automatic heat transfer machine

2. Pneumatic, hydraulic heat transfer machine

3. Roller heat transfer, heat stamping machine

4. Fusing machine

5. 3D vacuum heat transfer mahcine

 Q2: Are you a manufacturer?

-Yes, we have been in proving professional solutions in printing industry with 14 years from 2001.

Q3: What should you know if I want to get a quotation?

-The printing size, quantity, color and your specific address.

-If you have own logo, pls let us know the picture and details.



Q4: How many days will machines be finished and MOQ?

-According to the size and quantity of machine, small size machines can be finished in 3 days, large size machines can be finished in a week.

-MOQ: 1 set



Q5: Do you inspect the finished products?

-Yes, each step of production and finished products will be carried out inspection by QC before shipping.



 Large format multifunctional roller transfer printing machine roll to roll heat sublimation
