Home > Products > 2 Ton-3 Ton Wheel Loader > SZM Wheel Loader With Fork
SZM Wheel Loader With Fork
- QINGDAO
- T/T Money Gram
You May Like
Product Details
| Condition | New | Brand Name | SZM,CTK,SZMC,NEO | |
| Model Number | 930L | Place of Origin | Shandong, China | |
| Type | Front Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | 6500*2160*3050mm | Rated Load | 2800KG | |
| Certification | CE |
Product Description
Performance and characteristic:
1. Equipped with Deutz Engine ,optional Yuchai 6108, Dongfeng Cummins
2. High quality self-made hydraulic gearbox and driving axle.
3. Choose best hydraulic components, pilot operation, easy and durable.
4. Strong and durable frame, have the automatic flat function in high place.
5. (Quick change )option attachment: wooden fork, pipe, pallet fork, grass fork, rock bucket, bigger bucket, snow bucket, mixing bucket etc.
6. Luxurious cab, cab rollover, easy to keep and operate.
7. Changeable luxurious meter, air conditioner, back camera, more comfortable for driving.
8. High pressure and safer air assist disc brake braking system
9. According to clients request, customize higher dumping and longer arm products.
Specifications
Model | 930L |
Bucket capacity | 1.5m³ |
Rated load | 2800 kg |
Wheel base | 2350mm |
Wheel tread | 2150mm |
Min. ground clearance | 380mm |
Max. dumping height | 3500 mm |
Dump distance | 1080mm |
Total times | 9s |
Operation weight | 7000kg |
Engine model | HUAFENG4108 Turbo-charged |
Rated power/ speed | 83kw/2400 rpm |
Overall dimension (L*W*H)
| 6500*2160*3050mm |
Tyre | 16/70-24 |
