Performance and characteristic
1.Engine has the characteristic of high reliability and fuel economy.
2.Fully hydraulic steering system ,make it safety and dependability, easy to operate.
3.Torque converter and counter-shaft transmission gear box-Komatsu technology, assembled separately, higher reliability and easier maintenance.
4.Bucket can be leveled automatically, optimized working device, higher productivity.
5.The cab is grand and nice, with wide eyeshot and good sealing.
6.The manipulation table and seats are adjustable. The arrangement of the manipulation ,handle and instruments are reasonable, with convenient application, and the comfortable of driving is improved.
7.Select part: Can allocate many kinds of selectable assembly such as wooden fork, pipe fork, grass fork, stone bucket, enlarged bucket etc., to meet the needs of various working states.
Specification
Model |
912 |
Bucket capacity |
0.5m³ |
Rated load |
1600 kg |
Wheel base |
2150 mm |
Wheel Tread |
1400 mm |
Min. ground clearance |
380mm |
Max. dumping height |
2700 mm |
Dump distance |
860mm |
Total times |
10s |
Operation weight |
3700kg |
Engine model |
Xinchai |
Rated power/ speed |
32kw/2200 rpm |
Overall dimension(L*W*H) |
5210*1760*2580mm |
Tyre |
23.5-16 |
Quality Certificate
CE certification
Attestation of Compliance: No.OT121002/QSM1421
Services &Transportation
24 hours technical support by Email or calls
Engineers available
Warranty for one year, expecting for consumable parts
Show room
Exhibition picture
Attachments
ADVANTAGES |
|
²Powerful strength ²Reliable performance ²Environmental & economical ²Safety & durability
l Spacious canopy provides the operator with ample legroom
l Joystick with electric forward/reverse switch
l The pump and control valve made in Italy
l Floor-mounted inching pedal gives the operator excellent simultaneous control of travel and equipment hydraulic speeds
l Wide engine hood opening angle provides outstanding service access |
HOT SALE PRODUCT
Contract: Jennifer
MOB: +86 18853619708
Skype: evergreenjennifer
