Home > Products > Wire Series > Wholesale Black Wire Steel Wire Rope(manufacture)
Wholesale Black Wire Steel Wire Rope(manufacture)
- TianJin
- T/T Money Gram
You May Like
Product Details
| Standard | AISI, ASTM, DIN, GB, JIS | Grade | Other, steel | |
| Wire Gauge | 0.5mm-50mm | Length | 10m-2000m | |
| Application | lifting,drawing,bunding,elevator,shiping,hoisting and pulling | Certification | ISO | |
| Place of Origin | Hebei, China | Brand Name | oushijia | |
| Model Number | osj-wr-009 |
Product Description
black wire steel wire rope
Standard | ISO,GB/T,BS,DIN,JIS,ASTM,AS,AISI. |
Materia | 302,302L,304,304L,316,316L . carbon steel , 60# , 65#, 70#, 72A, 82B |
Construction | 1X7, 1X19, 7X7, 7X19, 6X7+FC/IWS, 6X19+FC/IWRC, 6X19S(W)+FC/IWRC, 6X37+FC/IWRC, 6X36WS+FC/IWRC, 19X7, 18X7+FC etc. |
Wire Gauge | 0.5mm-50mm |
Core | fiber core & steel core |
tensile strength | 1270Mpa-1970Mpa |
Application | lifting,drawing,bunding,elevator,shiping,hoisting and pulling |
partial specifications
| STRUCTURE | DIAMETER(±5%)/mm | BREAKING STRENGTH≥N | LINEAR DENSITY(±5%)/(g/mm) | LENGTH(m) |
| 3+9+15×0.22+0.15 | 1.62 | 2700 | 8.5 | 2000 |
| 3+8×0.33HT | 1.36 | 2650 | 7.48 | 2700 |
| 0.25+6+12×0.225HT | 1.1 | 2225 | 6.05 | 3500 |
| 3×0.20+6×0.35HT | 1.13 | 1800 | 5.34 | 3500 |
| 3×0.20+6×0.35NT | 1.13 | 1500 | 5.34 | 3500 |
| 3+9×0.22 | 0.92 | 1210 | 3.62 | 5000 |
| 3+9×0.22+0.15 | 1.18 | 1210 | 3.85 | 4000 |
| 1×12×0.20+0.15CC | 1.1 | 920 | 3.12 | 5000 |
| 3+9+15×0.175+0.15 | 1.34 | 1680 | 5.4 | 3100 |
| 3×0.20+6×0.38 | 1.2 | 1700 | 6.16 | 3300 |
| 2+7×0.28HT | 1.06 | 1560 | 4.45 | 4300 |
| 2+2×0.38 | 1.01 | 1020 | 3.56 | 5000 |
| 2+2*0.35HT | 0.94 | 980 | 3.03 | 6000 |
| 2+2×0.30HT | 0.8 | 800 | 2.23 | 8000 |
| 2+2×0.28HT | 0.73 | 710 | 1.94 | 10000 |
| 2+2*0.25HT | 0.65 | 560 | 1.55 | 13000 |
| 3×0.30HT | 0.65 | 660 | 1.68 | 10000 |
| 2×0.30HT | 0.6 | 445 | 1.12 | 16250 |
If you need other specifications,pls contact with me,we have all kinds.
Tel:+86 18631875281
Packing in reel or roll then into pallet or as the customers' requirement
We can supply sample freely ,but the freight need to be paid by the customer.
