Specifications
RFS Automatic Packing Machine(filling and sealing machine) for food in the bags. Horizontal packing machine.RFS Automatic Packing Machine(filling and sealing machine)
Function and characteristics:
1.Easy to operate,adopt advanced PLC from Germany Siemens, mate with touch screen and electric control system, the man-machine interface is friendly.
2.Frequency conversion adjusts the speed: this machine uses frequency conversion equipment, can be adjusted within the range according to the needs of reality in production.
3.Automatic checking: no pouch or pouch open error, no fill, no seal. the bag can be used again, avoid wasting packing materials and raw materials.
4.Safty device: Machine stop at abnormal air pressure, heater disconnection alarm.
5.Horizontal conveyer style to giving bag: it can put on more bags on the bag storage and have a low requirement about the quality of bags.
6. It can adjust the clips of the six working position at the same time, just need adjust one of the screw which is control the wide size of bag, then the all clips will adjust to the same width. It can save the time and suitable for more different size of bags, especially suitable for the customer who often adjust the wide size of bag.
7.Use the plastic bearing, dont need put on oil, less pollution.
8.Use no oil vacuum pump, avoid polluting the environment in the production.
9.The packing materials loss low, what this machine is used the preformed bag, the bag pattern is perfect and has a high quality of the sealing part, this improved the product specification
10.Product or packing bag contact parts adopt stainless steel or other materials which accord with the food hygienic requirements, guarantee hygiene and security of the food
11.With different feeders changed to pack solid, liquid, thick liquid ,powder and so on.
12.The packing bag suits in extensive range, suit for multi-layer compound, monolayer PE , PP and so on Preformed bag made by film and paper.
Specifications:
| Model | GD6-200C |
| Working position | six-working position |
| Pouch material | Laminated film |
| Pouch pattern | Stand-up,spout,falt |
| Pouch size | W:100-210mm L:100-350mm |
| Speed | ≤60pouches/minThe speed depends on the product status and flling weight |
| Weight | 1000KGS |
| Voltage | 380V 3phase 50HZ/60HZ |
| Total power | 1.5KW |
| Compress air | 0.6m3/min(supply by user) |
| Dimension | 2214(L)×1850(W)×1640(H)mm |
1.Giving bag
ding date
3.open bag
4.filling &vibrate
5.sealing
6.forming & output packages.
