Home > Products > 75kva--375kva Alternator > Double bearing Three Phase Brushless Alternator with AVR 6.5 Kw to 315KW for cummins generator
Double bearing Three Phase Brushless Alternator with AVR 6.5 Kw to 315KW for cummins generator
- 2500 Unit / Units per Month
- SHANGHAI
- T/T Credit Card
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | FARRAND | Model Number: | FLD274D |
Output Type: | AC Three Phase | Speed: | 1500rpm | Frequency: | 50HZ |
Rated Power: | 100kw | Rated Voltage: | 110V to 460V | Rated Current: | Amps |
Product Description
Specifications:
Brushless AC generator, suitable for operation at 1500 RPM, 170V and up to 454 Volts, 0.8 pf (lag) suitable for 50 Hz, 3 phase & 1 phase, 4 wire system. The alternator is designed and built to withstand tropical conditions. The alternator generally conforms to IEC 34-1/34-2 , BS 4999/5000 and IS: 4722-2001 with enclosures rating IP 23 is the standard version, satisfying IEC 34-5/IS : 4691/DIN VDE 0530-5 requirements. The Alternator is dynamically balanced , brushless type, screen protected, revolving field, self excited, self regulated through an AVR. The alternator has the following features:
1. +- 1.0 % Voltage regulation (max.) in static conditions
2. IP: 23 protection with insulation class H
3. Permissible overload of 10% for one hour in 12 hours of operation.
The generators have been designed for use in a maximum ambient temperature of 40℃ and altitude less than 1000M above sea level.
Arranges in order all voltages may obtain from the single wide wingding ,also namely(three -phase) and 4(single -phase) reorganizes through 12 terminals may obtain.
Other special voltage can be met by Farrand company.
Purchasing a FLD Series from us will include the following specification at no additional cost:
· 4 Poles
· Three Phase
· power factor 0.8
· 1500rpm
· 50hz
· Available voltage from 170v and up to 454v
· 4 lead alternator
· Class H insulation
· IP23 enclosure
· High efficiency
· Automatic Voltage Regulator
Brushless AC Generator | |||
Output Type | AC Three Phase | ||
Rated Power | 32KW | Rated Capacity | 40KVA |
Frequency | 50HZ | Speed | 1500RPM |
Voltage | 170V-454V | Ingress Protection | IP23 |
AVR | SX460 | Power Factor | 0.8 |
Port of loading | Shanghai | Warranty | one year |
Below you will find all the specific models associated with the FLD series.If you have any questions or need pricing please contact us.
For 3-Phase 4 Pole alternators
4-Pole Farrand brushless alternator specifications 1/3 phase H Class Temperture-rise(125°C) | ||||
Rating Power Factor | 0.8/1 | |||
Altitude | 1000m | |||
Insulation Class | H | Excitation System | Shunt | |
Lead Number | 12 | A.V.R Model | SX460/MX321/MX341/SX440/SX440T/AS440 | |
Winding Pitch | 2 / 3 | Voltage Regulation | ±1% | |
Ingress Protection | IP 22 / 23 | Transient Voltage Recovery Time(s) | ≤1.0 | |
Waveform:NEMA-MG1 | ≤50 | Waveform:IEC-THF | ≤2% | |
Ambient Temperature | 40° C | 40° C | 40° C | 40° C |
Temperature Rise | 125° C | 150° C | 125° C | 150° C |
Phase / Insulation | 3 Phase / H Class | 3 Phase / H Class | ||
Frequency | 50Hz(1500rpm) | 60Hz(1800rpm) | ||
Voltage ( V ) | 170-454 | 110-240/230-460 | ||
Type | Capacity | Capacity | ||
Rated capacity/kva | Rated power/kw | Rated capacity/kva | Rated power/kw | |
FLD164A | 8.1 | 6.5 | 10.2 | 8.2 |
FLD164B | 11 | 8.8 | 13.8 | 11 |
FLD164C | 13.5 | 10.8 | 16.9 | 13.5 |
FLD164D | 16 | 12.8 | 20.2 | 16 |
FLD184ES | 20 | 18 | 25 | 20 |
FLD184E | 22.5 | 18 | 28.8 | 23 |
FLD184F | 27.5 | 22 | 34.4 | 27.5 |
FLD184G | 31.3 | 25 | 37.5 | 30 |
FLD184H | 37.5 | 30 | 46.9 | 37.5 |
FLD184J | 40 | 32 | 50 | 40 |
FLD224C16 | 42.5 | 34 | 52.5 | 42 |
FLD224D16 | 50 | 40 | 62.5 | 50 |
FLD224E16 | 62.5 | 50 | 72.5 | 58 |
FLD224F16 | 75 | 60 | 87.5 | 70 |
FLD224G16 | 85 | 68 | 100 | 80 |
FLD274C14 | 100 | 80 | 125 | 100 |
FLD274D14 | 114 | 91 | 138 | 110 |
FLD274DL14 | 125 | 100 | 156 | 125 |
FLD274E14 | 140 | 112 | 168 | 134 |
FLD274FS14 | 150 | 120 | 187.5 | 150 |
FLD274F14 | 160 | 128 | 190 | 152 |
FLD274G14 | 175 | 144 | 213 | 170 |
FLD274H14 | 200 | 160 | 245 | 196 |
FLD274J14 | 225 | 180 | 281 | 225 |
FLD274K14 | 250 | 200 | 320 | 256 |
FLD444C14 | 250 | 200 | 320 | 256 |
FLD444D14 | 294 | 235 | 380 | 305 |
FLDK444D14 | 313 | 250 | 390 | 312 |
FLD444E14 | 325 | 260 | 394 | 315 |
Information for AVR:
We have many types of AVR,such us SX460, SX440, SX421, MX341, MX321,etc.
· The main stator provides power for excitation of the exciter field via AVR.
· Output power of exciter's rotor is input to that of mains through 3-phase full wave rectifier.
· Connected with piezoresistance for restraining surge voltage and avoiding the impact caused by short circuit or parallel synchronization loss.
· Exciter's Stator is equipped with permanent magnetic steel, it can make generator starting smoothly in any occasions.
· Voltage regulation (0.5 %) and low frequency protection, exterior voltage adjustment of SX440, MX341 and MX321 suitable for the generator with permanent magnetic generator (PMG).
Features:
1. Any permanent magnetic alternators,providing invariable excitation on all occasions.
2. Easy to be connected with power network or other alternators.Standard 2/3 pitch windings check excessive midline current.
3. Balanced rotor with single or two sealed ball bearings.
4. Convenient installation and maintenance with easy access to terminals,rotating diodes and coupling bolts.
5. Wide range of flange adaptor and single bearing coupling disc
6. Meet leading standards.
ELECTRIC FEATURES:
Insulation
Insulation class H
All regulatory components are made up with special materials and are immersed in lacquer by peculiar tech. Varnish and colophony materials are developed to strengthen the proce for protecting the alternator work under corrosive environment.
Winings and electric features:
2/3 pitch windings design can effectively eliminate the third harmonica wave(3rd,9th,15th)of the voltage,which is the best design of UPS for nonlinear load.Connected with the network in parallel,the structure can restrain excessive currents in the midline.
A continous damp windings abates surges.The poles and gears of the windings are carefully chosen,this and the 2/3 pitch help to check the wave distortion of output voltage.
Phone interference:
THF (defined by 40th part of BS4999)<=2%.TIF(defined by ASAC50.12)<=50.
Radio interference:
Brushless apparatus and quality AVR ensure little radio interference in transmission.RFI noise filter is also avaiable.
The advantage of our material:
· The rotors and stators with 100% copper wire.
· The enamelled wire is Essex by America.
· The silicon steel sheet we use is the products of Wugang Brand,800 Series.which is the most famous manufacture of steel.And its advantage is its magnetic flux is large and its iron loss is small.
· The main frame of the alternator and lead box are made of steel,the end cover is made of high strength cast iron.
· All the components of our factory,the stator,rotor and excitation will be dipping lacquer twice.
· The rope of best nylon to be used in all the rotors and stators.We promise the security of our products,the phenomenon of ribbon burst will never happen.
· The TWB bearings are useing in our products.
· All the rotors should be tested by dynamic balance of Germany to go on test of balance. All the products should be tested by specialized Test Room.
Our staff of sales and technical support is available to help you in selecting the right protection for your application as well as to provide you with samples of our products for evaluation. At High Five, we are committed to providing the highest level of customer service, competitive pricing, speedy delivery and a comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Jiangsu Farrand Generator Technology Co.,Ltd is a professional large-scale manufacturer of all types of alternator,integrating development and production together.Our main products include alternators from 6.5kw(8kva) to 1000kw(1250kva), voltage from 110V to 480v, silent type,single or three phase,synchronous brushless. All interface according to international standard, matching all generators in the world. Such as Cummins, deutz, MTU, perkins, Volvo .
Farrand Generator company Located near Shanghai, we enjoy convenient water, land and air transportation. It covers an area of more than 5000m2. we have good cooperation technical and produce team.Our motto “The quality of products is the company’s life”With the motto,we make concerted efforts. Farrand carry out high standard technical regulation, techniques, strict quality inspection and mature quality guarantee system in order to manufacture world-class high quality motors.
Currently, Farrand Generator is already exported to Middle East,Europe, Australia,Russia and 12 other countries and regions. Our company has always focused on research, development and innovation,we will initiate the second phase of our development strategy. Our company regards “reasonable prices, efficient production time and good after-sales service” as our principle.
Thank you for visiting our website. We hope to cooperate with more customers for mutual development and benefits.Sincerly wish to cooperate with friends all over the world.
Q. How much will the shipping of my order cost?
A.Our shipping costs are calculated depending on the total weight and measurement CBM of the items you wish to purchase and your destination.We always do our best to keep the shipping costs to a minimum.Our forwarder has a long contract with us,we can get a big discount for you.
Q.How long does a sample takes?
A. If we have in stock,a sample will be delivered less than 3days.
Usually a sample takes 5 days.Please contact us which type that you needs,we will show you delivery time immediately.
Q.What is the MOQ of the product?
Our MOQ can meets your promotional business very well.
Q.Do you accept OEM?
Yes,we do.We can match any your samples.
Q.What is the level of ingress protection?
Ingress protection 22 standard,IP23 can be choosed.
Q.How many types of AVR do you have?
Such as SX460,MX321,MX341,SX440,SX440T,AS440,etc.
Q.How long is your quality guarantee period?
A.All alternators are warranted for 12 months from the notify date of waiting transportation.
