Help CenterHot Selling Atm Chip Nfc Pinpad Smart Card Reader For Andriod HCC990
Related Products
-
Hcc Mpos With Payment Pos Pinpad Machine-HCC890US$ 58 - 63MOQ: 1 Unit -
Payment Method Mpos With Pinpad Card Reader-HCC810US$ 31 - 36MOQ: 1 Unit
-
China Payment Machine Security Pinpad Terminal -HCC890US$ 58 - 63MOQ: 1 Unit
-
Hcc E-payment Atm Security Pinpad Terminal --E4021US$ 75 - 85MOQ: 1 Unit
-
E-payment Android Tablet Smart Card Reader Pinpad Keypad With Slot Reader for Magnetic Stripe & Barcode-HCC810US$ 31 - 36MOQ: 1 Unit
General
HCC990 is a Pinpad which perfectly combine the magnetic card reading, contact card reading & writing, contactless card reader/writer . It is mainly designed to meet the needs of problem’s coexistence of magnetic card / contact IC card and contactless IC card in card system.
HCC990 has two supported interfaces that USB or RS232.The Main contact card adopt dropping cassette deck, power supply through keyboard wedge or USB interface which equip no drive technology.
HCC990 have an external interface and an semi-buried interface which support a small SAM cassette deck.Main cassette deck adopt common usage mode, accessory cassette deck can be easily inserted administrator card which support authentication and administration. It is deal with the way of most read-write authentication card must use built-in SAM card. At the same time,it adds a built-in SAM cassette deck to meet the requirements of compatibility and multipart authentication.
Feature
HCC990 adopt HID no-drive technology of USB that make the process of system installation and usage more conveniently,it also equipped with the function of online update and custom-made adhibition for various users.
In order to coordinate transaction velocity of money,all cassette decks support high speed CPU card.
HCC990 multi-card reader as an IC card system integration necessary front-ens processing equipment, greatly improved the safety and ease of application systems.
It is much suitable for bank network, insurance, medical treatment, tariff and POS system.
Specification
Name |
HCC990 multi-card reader and writer |
weight |
400g |
Working environment |
-20 - 60 |
Life time of contact card |
200000 |
Size of card |
support iso7816 card and 1 SAM cassette deck accord with GSM 11.11 SIM card |
Power supply |
70 mA |
Communication Interface |
Standard RS232 interface or USB interface( HID no-drive) |
|
Communication protocol
|
support CPU card(T=0/T=1),common memory card.the speed can up to 115,200 bps Support ISO14443 Type A, Type B contactless card .Such as:Mifare S50,Mifare S70,MF1ICL10,Mifare Pro,Mifare desfire,Mifare ultralight,SLE44R31,SLE6-6cl serials,AT88RF020,Huahong 1102 and etc.
|
Standard |
ISO14443,ISO 7816-3,PC/SC,GSM11.11,FCC, CE |
Communication speed |
T=0:9600-38400bps T=1:9600-115200bps |
Color |
Generally black,it is also can be custom-made |
connecting cables |
2M |
Status Display |
Two-color LED to indicate power or communication state |
Keyboard support |
Support keyboard input, keyboard with 15 keys, content keys 0-9 number keys and "OK", the "Clear" three spare keys, 3DES encryption support, available with pronunciation. |
Storage Support |
Provide 4K read-write space and the corresponding interface functions, the device ID can be set up for users to store data |
Magnetic stripe card support |
Support 1 2 3-track magnetic stripe card reader |
operating system |
Windows 98, Me, 2K, XP, 2003 and Linux and Unix |
Size |
150mm*110mm*62mm |
|
Other features
|
Provide a common interface library to support multiple operating systems and language development platform |
