poe rfid reader/finger print card access control biometric-SCR100
Introduction:
SCR100 is an access control devices produced, which is made with elegant design and professional surface treatment. The device have lock control, alarm, exit button, door sensor. The wiegand-in interface is used to connect external reader to construct master and slave system. Also the device can be used to connect with a control panel as a reader by wiegand-out interface. The operation can be done on PC software and upload to the device through TCP/IP, RS232/485 communication. The USB-host is used for data download and upload, including user data and record etc. SCR100 is suitable for house, small office and factory etc.
Features:
l Elegant casing design
l Easy installation, safe and reliable
l Simple and convenient operation method
l ID card standard
l Full door lock control system
l Wiegand out to connect with control panel
l Wiegand in to construct master and slave system
l Audio prompt and LED feedback guide the user to operate
Specifications
ID card Capacity |
30000 |
Transaction Capacity |
50000 |
Communication |
TCP/IP, RS232/485, USB-Host |
Access Control Interface for |
3rd party electric lock, door sensor, exit button, alarm, Door Bell |
Wiegand Signal |
Output&Input |
Standard Functions |
Anti-passback, Webserver, 9 digital number |
Optional Functions |
HID |
Display |
N/A |
Power Supply |
12V DC |
Operating Temperature |
0 ℃- 45 ℃ |
Operating Humidity |
20%-80% |
Dimension(L*W*H)mm |
153x95.5x35.5 |
Gross Weight |
0.8KG |
