USB interface for Olivetti High Quality Printer for Bankbook-PR2E

Mode

OLIVETTI PR2E/K10  Standard pattern

OLIVETTI PR2E/K12  Standard pattern + read-write component of horizontal magnetic strip

Printing type

Matrix printing, bi-directional prediction and logical distance selection

Printing head

24 needle lift type printing head with the needles arranged in the form of Olivetti

Printing Speed

Ultrahigh speed                   High speed     Draft

Chinese Character(words/second)     /          155

ASCⅡ(words/second)              460         350

Emulation    letter type    Letter type

  135            60          45

  260           130          86

Chart Speed

1/6″, Time for line shift is about 45ms

Processing mode of papers

Automatic rectifying a deviation, automatic aligning, automatic regulating the printing thickness

Printable Media

Single sheet of paper,Multi layer carbon paper,Bankbook,Check

Printing dimension

Single sheet of paper:65-245mm in width, 70-297mm in length

Bankbook:150-241.3mm in width, 165-220mm in length

Printing dimension

Single sheet of paper:65-245mm in width, 70-297mm in length

Bankbook:150-241.3mm in width, 165-220mm in length

Coping power

1+4 layers

Maximum printing thickness

2.0mm

Ink ribbon

Special major ribbon cartridge and black ink ribbon, the service life being about 3,500,000 characters

Able to process multifold word gap, regulate the word gap and the proportional word gap, and provide multifold properties of the printing character

Printing word gap:ASCⅡ Character:10,12,16.6,17.1CPI

Chinese word:5,6,6.9,8.3,8.5CPI

line feed pitch:1/6″,1/8″,n/120″,n /180″,n /216″,n/240″

Supporting such printing properties of Chinese and western character as overline and underline, superscript and subscript, bold, inverted, hollow and grid font, italic, rotation, multiple height, doubling width, doubling height, and various combination of height and width

Font

Font of Chinese character:GB18030 Song-Dynasty-style Font

Font of English character:VHSD,HSD,DRAFT,NLQ1,NLQ2,LQ,OCR-A,OCR-B

graphic printing(Point/inch)

Horizontal:60,72,80,90,96,120,180,240

Perpendicular:180,216

Interface

Standard RS-232C serial port, Centronics IEEE1284 parallel port

Emulation Mode

Compatible with OLIVETTI Printer PR40,PR2 and IBM ProprinterⅡ; Several emulation modes including PPDS and OKI etc.

Dimension

384×280×199mm (Width× Length× Height)

Weight

9.5 kilograms (Standard Pattern)

10.5 kilograms (Standard Pattern with the read-write component of horizontal magnet

Acoustic Noise

<53dB

Voltage

220±15%

Frequency

50Hz±1Hz

Power Consumption

Static 12W  Maximum 170W

Environmental Requirement

Temperature:5℃-35℃   Humidity:15%-85%
