Specifications
Internal Concrete Vibrator MotorDYNAPAC Maylasia Type,Japanese Type,Australia Type
Diesel,Electric vibrator motor available
Internal Concrete Vibrator Motor
CONSMAC SVE series high performance Internal Concrete Vibrator Motor is the drive unit for various concrete vibrator shaft with various couplings. Large choice of power from 1.1kw to 2.2kw, and rotary speed from 2840rpm to 12000rpm. Three phase and single phase motors are available.
Internal Concrete Vibrator Motor Coupling Choice:
1. DYNAPAC Coupling
2. Japanese Coupling
3. Ball Type Coupling
4. Pin Type Coupling
5. Other coupling like Australia type, Russia type can be available, based on customers' choice.
Internal Concrete Vibrator Motor Specification:
| Model | SVE-J | SVE-B | SVE-DF | SVE-D |
| Coupling Type | Japanese type | Japanese type | Dynapac type | Dynapac type |
| Power | 1.1kw, 1.5kw, 2.2kw | |||
| Voltage | 110V, 220V,380V | |||
| Rotary Speed | 2840rpm | |||
| Model | SVE-P | SVE-PF | SVE-JF | SVE-S |
| Coupling Type | Pin type | Pin type | Japanese type | screw hexagonal |
| Power | 1.1kw, 1.5kw, 2.2kw | 1.6kw | ||
| Voltage | 220V, 380V | 220V | ||
| Rotary Speed | 2840rmp | 5600rpm | 5600rpm | 12000rpm |
All CONSMAC Internal Concrete Vibrator Motors are available for online purchase with fast delivery.
Please feel free to contact us at Phone No: 0086- 574- 88192352, or send us enquiries on line, all your mails will be replied within 24 hours.
