Gasoline Robin Concrete Vibrator

Gasoline Robin Concrete Vibrator thumbnail-1
Gasoline Robin Concrete Vibrator photo-1
US$ 30 - 60 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
CONSMAC
Model Number:
SVD-R
Contact Supplier Request Quote Chat Now
Consmac Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name CONSMAC
Model Number SVD-R

Specifications

Gasoline Robin Concrete Vibrator
Honda GX160,5.5hp,4.0kw
DYNAPAC Type, Australia Type can be available

Gasoline Robin Concrete Vibrator



CONSMAC SVD series Gasoline Concrete Vibrator is the drive unit for various concrete vibrator shaft.





Gasoline Robin Concrete Vibrator Coupling Choice:



1.  DYNAPAC Coupling

2.  Japanese Coupling

3.  Ball Type Coupling

4.  Pin Type Coupling

5.  Other coupling like Australia type, Russia type can be available, based on customers' choice.





Gasoline Robin Concrete Vibrator  Specification:





Model SVD-H SVD-R SVD-L SVD-K
Engine Air-cooled, 4-cycle,single cyliner
Engine Type Petrol, Honda GX160 Petrol, Robin EY20 Petrol, Lifan 168F Diesel, Kama 170F
Power 5.5hp/4.0kw 5.0hp/3.6kw 5.5hp/4.0kw 3.8hp/2.8kw
Rotary Speed 3600rpm
Coupling Choice DYNAPAC Type, Pin Type, Ball Type
Applications Concrete vibrator, submersible flexible pump
Weight 22kg(49lbs) 25kg(55lbs) 24(53lbs) 34(75lbs)
Packing 53*38*54cm(21*15*21in)





Gasoline Robin Concrete Vibrator





Concrete Vibrator Shaft



CONSMAC SVS series high-performance mechanical Concrete Vibrator Shaft. Large choice of couplings and diameters from 25 to 75 mm, drived by CONSMAC Diesel, Gasoline Concrete Vibrator(SVD series) and Electric Concrete Vibrator(SVE series)





Concrete Vibrator Shaft Coupling Option:



1.  Japanese type

2.  Dynapac type

3.  Russian type

4.  Turkish type

5.  Australian type

6.  Chinese square type

7.  Other couplings can be available, based on customers' choice.





Concrete Vibrator Shaft Specification





Model SVS25 SVS28 SVS32 SVS35 SVS38 SVS45 SVS50 SVS60 SVS70
Head Dia. 25mm 28mm 32mm 35mm 38mm 45mm 50mm 60mm 70mm
Length of Shaft Standard length:6m(1m-12m is available)
Hose outside Dia 24mm 25mm 30mm 32mm 36mm
Hose inner Dia 13mm 14mm 16mm 18mm 20mm
Shaft Dia 8mm 10mm 12mm 13mm
Frequency 230hz 210hz 200hz
Amplitude 1.1mm 1.11mm 1.13mm 1.15mm 1.18mm 1.2mm 1.21mm 1.28mm 1.32mm
Couple Choice Japanese type ,Dynapac type,Chinese square type,Australian type,Turkish type
Drive unit Electric motor, Petrol engine, Diesel engine
Packing size 85*65*6cm(33*25*2.5in)
Optional Outer Liner, Spring





All CONSMAC Gasoline Robin Concrete Vibrator are available for online purchase with fast delivery.

Please feel free to contact us at Phone No: 0086- 574- 88192352, or send us enquiries on line, all your mails will be replied within 24 hours.
