Help CenterIndian Manufacturer of Worm Drive Limit Switches
Related Products
-
Flameproof Weight Operated Limit SwitchesNegotiableMOQ: 1 -
Cross Rotary Limit Switches ManufacturerNegotiableMOQ: 5 Units
-
Flameproof Lever Operated Limit Switch ManufacturerNegotiableMOQ: 1
-
Cross Rotary Limit SwitchesNegotiableMOQ: 5 Units
-
Lever Operated Limit SwitchesNegotiableMOQ: 5 Units
Specifications
1-Efficient distribution of forces2-Sturdy components
3-Long, trouble free service
Application-
Worm Drive Limit Switch FG are suitable for use on reversing drives,such as Hoists, Crane, Winches, Rolling Mills, Theater, Coke Oven etc.The driving motion is transmitted by worm gear. All gears and hubs are made of low wear thermoplastic. The rotational movements are transmitted to switches by adjustable cams.
| Body Material | Black GFN |
| Cover Material Yellow | Impact-proof Thermo- Plastic |
| Protection Degree | IP-55 IS : 13947 Part 1 |
| Operating Temperature | - 25°C to 70°C |
| Mounting Position | All position mounting |
| Gear Ratios | 1 : 12.5, 1:25, 1:50, 1 : 100, 1 : 200 and 1 : 400 |
| Drive | Worm Screw |
| Cable Entries | Twin, 3/4 “ BS Conduit |
| Input Speed | 1200 RPM, Maximum |
| Contact Material | Double brake, Silver Cadmium ( Snap ) |
| Wire Connection | Screw terminal contact |
| Rated valtage | up to 600 V ac |
| Thermal Test Current | 10A |
| No. Of Contacts | 2 No + 2 NC OR 4 No + 4 NC ( Max ) |
| Ratios | Useful Rotations | 2 Contacts Model 2 NC | 4 Contacts Model 4 NC |
| 1:12.5 | 11.6 | FG - 12.5 P2 | FG - 12.5 P4 |
| 1:25 | 23.2 | FG - 25 P2 | FG - 25 P4 |
| 1:50 | 46.5 | FG - 50 P2 | FG - 50 P4 |
| 1:100 | 93 | FG - 100 P2 | FG - 100 P4 |
| 1:200 | 185 | FG - 200 P2 | FG - 200 P4 |
| 1:400 | 372 | FG - 400 P2 | FG - 400 P4 |
Product Portfolio
Available with us is a praiseworthy range of Crane Control Gears that is suitable for use in varied industry applications. Manufactured using high grade raw material, these control gears are assured to feature a longer functional life. As these are based on latest technology, it is proved that their performance will be reliable and efficiency unquestioned. Hosting such beneficial features, these products are demanded across the globe on a large scale.
Listed below are the products offered by us:
- Electro Hydraulic Thrusters ELDRO
- Safe-Duct Enclosed Conductor Bar System
- Thruster Brakes SMD
- Thruster Brakes MDT
- Electro Hydraulic Thrusters ST
- D.C.E.M. Brakes (DMB)
- D.C. Electro-Magnetic Brakes
- A.C Electro Magnetic Brakes
- Resistance Boxes PS/SS
- Resistance Boxes
- Flame Proof Thrusters / Brakes
- Lever / Weight Limit Switches
- Rotary/Worm Limit Switches
- Shrouded Busbar Systems
- Radio Remote Control
- Couplings
- Master Controllers
- Anticollision Device for Cranes
- DSL Indicating Lamp
