Home Solar System Storage Battery12V150ah

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Port Tianjin
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China	Brand Name	Aoguan
Model Number	6-CNFJ-150	Type	Other, gel
Nominal Voltage	12V	Size	Other, 483170238mm
Nominal Capacity	150ah

Product Description

home solar system storage battery12V150ah

FEATURES

Maintenance-Free Operation

Absorbent Glass Mat (AGM) technology ensures efficient gas recombination up to 99% and freedom from electrolyte maintenance. During the expected float service life of batteries, no need to check the specific gravity of the electrolyte or add water.

Good Discharging Ability

Tight assembly technology ensures an excellent high-rate discharge performance.

Long Service Life

A unique corrosion-resistant grid alloy ensures batteries have long service life.

Low Self Discharge

Using high purity raw materials ensures batteries have less self-discharge.

Environmental & Non-polluting

Gas Recombination technology ensures the battery high seal reacting rate

PARAMETERS

No.	Model	Rated Voltage V	Rated Capacity	Dimensions(±2mm)				Weight KG	Connection
No.	Model	Rated Voltage V	Rated Capacity	Length	Width	Height	Total Height	Weight KG	Connection
1	6-CNFJ-24	12	24AH	204	165	175	175	12.00	Lead wire
2	6-CNFJ-38	12	38AH	204	165	175	175	12.70	Lead wire
3	6-CNFJ-50	12	50AH	270	165	169	169	14.80	Lead wire
4	6-CNFJ-55	12	55AH	270	165	169	169	16.50	Lead wire
5	6-CNFJ-60	12	60AH	351	170	179	179	18.90	Lead wire
6	6-CNFJ-65	12	65AH	351	170	179	179	20.40	Lead wire
7	6-CNFJ-75	12	75AH	338	172	215	218	23.20	Lead wire
8	6-CNFJ-80	12	80AH	338	172	215	218	24.00	Lead wire
9	6-CNFJ-90	12	90AH	338	172	215	218	27.20	Lead wire
10	6-CNFJ-100	12	100AH	338	172	215	218	31.50	Lead wire
11	6-CNFJ-120	12	120AH	413	174	210	212	36.50	Lead wire
12	6-CNFJ-135	12	135AH	483	170	238	238	40.70	Lead wire
13	6-CNFJ-150	12	150AH	483	170	238	238	43.40	Lead wire
14	6-CNFJ-180	12	180AH	523	240	220	220	57.90	Lead wire
15	6-CNFJ-200	12	200AH	523	240	220	220	60.00	Lead wire
16	6-CNFJ-230	12	230AH	523	240	220	220	62.00	Lead wire
17	CNFJ-200	2	200AH	169	105	330	360	13.00	Terminal
18	CNFJ-300	2	300AH	171	151	330	360	19.50	Terminal
19	CNFJ-400	2	400AH	211	172	330	360	25.50	Terminal
20	CNFJ-500	2	500AH	241	172	330	360	32.00	Terminal
21	CNFJ-800	2	800AH	410	176	330	360	51.00	Terminal
22	CNFJ-1000	2	1000AH	475	175	330	360	62.50	Terminal

APPLICATIONS

Solar system and Wind system
Emergency lighting equipment
Fire alarm and security systems
Telecommunication equipment
Electric equipment and telemeter equipment
Light equipment
Wireless lawn movers vacuum cleaner and washing machine
Toys and consumer electronics
Portable power tools measuring and medical equipment Portable video camera portable personal computer
Garden lighting.

Use and maintenance

Please use constant-voltage charge.
In floating charge, the voltage is 2.23 to 2.27 per unit cell.In cycle use,
the voltage is 2.35 to 2.45 per unit cell,the max.current is no more than 25%C
Please do tighten the bolts to avoid sparkle and poor contact when the battery is in use
Please do not use it near the heat source and open flame
Please keep it at low temperature.Please change it while there is liquid leaking or damage
