Specifications
1. hydraulic bolt tensioner2. widely application
3. simple and convenient
Hyrdualic bolt tensioner
♦High precision, fast speed and safe
♦Wide range application for various bolts
♦Simply to operated
Hydraulic bolt tensioners was wildly application scope, involving various industrial fields,Metallurgy, mining, oil chemical industry, reactor, engine, pump, motor, compressor, heat exchanger, large transmission equipment, port machinery and material handling, wind power generation, etc
Accurate and Fast - Simultaneous multiple tensioning
Reliable- Robust Cylinders designed through multiple engineering calculations
Quality and Safe - high strengths materials of aircraft grade alloys
Quick and Easy - Incorporating quick disconnects nipples
Wide tooling range for different bolt/stud sizes up to 500 Ton
| model | adaptable (M) | oil area (cm3) | pressure Mpa | pulling force KN | tensioning KN |
| FY-M 3.5 | M30Χ3.5 | 24.54 | 60.7 | 157 | 251 |
| FY-M 4 | M36X4 | 30.60 | 71.8 | 230 | 366 |
| FY-M 4 | M39X4 | 35.6 | 73.66 | 275 | 401 |
| FY-M 4.5 | M42X4.5 | 50.34 | 59.4 | 315 | 502 |
| FY-M 5 | M48X5 | 53.00 | 73.35 | 415 | 659 |
| FY-M 5.5 | M56X5.5 | 68.9 | 79.1 | 576 | 909 |
| FY-M 6 | M64X6 | 94.2 | 68 | 762 | 1198 |
| FY-M 6 | M72 X6 | 125 | 76.3 | 991 | 1551 |
| FY-M 6 | M80 X6 | 159.54 | 72.7 | 1247 | 1946 |
| FY-M 6 | M90 X6 | 213.5 | 69.8 | 1605 | 2504 |
| FY-M 6 | M100 X6 | 226 | 74.3 | 2011 | 3136 |
| FY-M 6 | M110 X6 | 275.5 | 74.57 | 2469 | 3834 |
| FY-M 3 | M120 X6 | 371 | 66.3 | 2911 | 4614 |
| FY-M 6 | M130 X6 | 388.58 | 74.9 | 3346 | 5452 |
| FY-M 6 | M140 X6 | 452.16 | 75.2 | 3832 | 6361 |
| FY-M 6 | M150 X6 | 647.60 | 60.6 | 4415 | 7329 |
| FY-M 6 | M160 X6 | 371 | 61.89 | 5184 | 8377 |
| FY-M 6 | M170 X6 | 803 | 63.3 | 5811 | 9237 |
| FY-M 6 | M180 X6 | 876 | 35.4 | 6617 | 10410 |
| FY-M 6 | M190 X6 | 1036 | 82 | 7395 | 11624 |
| FY-M 6 | M200 X6 | 1170 | 81 | 8221 | 12928 |
| FY-M 6 | M210 X6 | 1236 | 95 100 | 8850 | 13890 |
| FY-M 6 | M220 X6 | 1302 | 100 125 | 9680 | 14980 |
Brief Intronduction of FEIYAO
Established in 1978, Jiangsu Feiyao Machinery Manufacturing factory is an professional leading manufacturer of hydraulic tools in China. Such as PLC lifiting systerm, hydraulic cylinders, torque wrench, nut splitter, flange spreader, gear pullers, hydraulic pumps and accessories etc.
Our products have been widely sold to Europe, South-east Asia and Middle East, and have got high appreciation and trust from all our customers. Whenever you need hydraulic products, please rememmber our company is always your reliable friends.
Our well-equipped facilities and excellent quality control enables us meet customers' satisfaction. Besides, we have gained CE and ISO9001 certificates.
We warmly welcome all overseas customers to talk with us about business or other cooperations.
Any phone call, E-mali, Fax from you would be a beginning of happy cooperation.
