Input Voltage Waterproof Constant Current 700ma Led Driver

Name: Input Voltage Waterproof Constant Current 700ma Led Driver
Brand: SHINE-TECHNOLOGY
SKU: 121318889

US$ 1 - 10 MOQ: 1000 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

SHINE-TECHNOLOGY

Model Number:

CC-40700C

Shenzhen Shine Technology Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name SHINE-TECHNOLOGY

Model Number CC-40700C

Output Power Other, 1 - 50W, 30W

Output Type Single

Input Voltage Other, 220V, 100-240VAC

Output Voltage 5-42VDC

Output Frequency 47 ~ 63 Hz

Output Current 700ma

Specifications

1.Aluminum Shell
2.100% full load burn-in test
3.Life time: 50,000 hours
4.Certificate: CE, RoHs

Detailed Images

Product Description

Features:
Protections: Short circuit/Overload/Over Voltage/Over Temperature
IP protection standard: IP67
100% full load burn-in test
Certificate: CE, ROHS
One and half years warranty
Cooling: By Convection
MTBF: Min250Khrs
Efficiency: more than 80%
Specifications:
Input Voltage		170-250VAC
Input current		0.16A
Input Frequency		47 to 63 Hz
Output Voltage		5-42VDC
Output current(Constant)		700mA
Max output Power		30W
Storage temperature:		-40-80 degree
Operating temperature:		-25-45 degree
Humidity operating:		20%-95%
Humidity storage:		10%-95%
Protections	Short Circuit	Auto recovery
	Over-load	20% exceed is allowed
	Over-voltage	≤255V
	Thermal Protection	≤85 degree
CE	CE Safety Standard	Compliance to EN61347-1:2008&EN 61347-2-13:2006
	EMI conduction & radiation	Compliance to EN 55015: 2006+A1: 2007 EN 61547: 2004
	Harmonic Current	Compliance to EN 61000-3-2: 2006 EN 61000-3-3: 1995+A1: 2001+A2: 2005
Others	Dimension/Weight	2003020MM/260g
	Packing/Carton Size	50pcs/carton / 342418cm
	Cable	0.75sq.mm. VED wire 200mm
	Housing Material	Aluminum
