Help CenterLED Power Supply 5V to 32V 900mA Constant Current 30w LED Driver
Related Products
-
Waterproof Constant Current 30W 30-85VDC/350mA Led DriverUS$ 2 - 8MOQ: 50 Pieces -
New Products 2014 5V to 32V 900mA Constant Current 30w LED Driver TransformerUS$ 2 - 8MOQ: 50 Pieces
-
Hot Selling Led Light Constant Current 18w 350MA Led DriverUS$ 1 - 8MOQ: 50 Pieces
-
Waterproof Constant Current 12w 350ma Led Driver TransformerUS$ 1 - 7MOQ: 50 Pieces
-
Constant Current 30W 30-85VDC/350mA Led Spotlight TransformerUS$ 2 - 8MOQ: 50 Pieces
Specifications
nstant current 30w LED Power Supply2.IP67 rated,CE RoHS,
3.100% full load burn-in test
4.1.5 years warranty
High quality Constant Current 30W LED Power Supply /900mA with ce&rohs
Specification: | ||||||
Model |
CC-32900C |
|||||
OUTPUT |
DC Voltage |
5-32VDC |
||||
Rated power |
30W |
|||||
Current range |
900±20mA |
|||||
INPUT |
Voltage |
170~ 250VAC |
||||
Frequency |
47 ~ 63 Hz |
|||||
AC Current |
0.19A max @220V |
|||||
Efficiency (Typ.) |
80% |
|||||
PROTECTION |
Overload |
20% exceed is allowing |
||||
Short Circuit |
Auto recovery |
|||||
Over Voltage |
≤255V |
|||||
Over temperature |
≤85Degree |
|||||
OTHERS |
Cooling |
By convection |
||||
Withstand voltage |
2200VAC |
|||||
Dimension/Weight |
200*30*20mm/260g |
|||||
Packing/Carton Size |
50pcs/carton / 34*24*18.5cm |
|||||
Cable |
0.75sq.mm. VDE wire 200mm |
|||||
Housing Material |
Aluminum |
|||||
CE |
CE Safety Standard |
Compliance to EN61347-1:2008&EN 61347-2-13:2006 |
||||
EMI conduction & radiation |
Compliance to EN 55015: 2006+A1: 2007 EN 61547: 2004 |
|||||
Harmonic Current |
Compliance to EN 61000-3-2: 2006 EN 61000-3-3: 1995+A1: 2001+A2: 2005 |
|||||
1. T/T West Union, 30% deposit after order confirmed, the balance before shipment.
2. Lead time: normally in 5-7 workdays after deposit received.
3. Sample policy: Samples are always available for each model. Deliver Immediately once payment received.
4. Shipping port: Shenzhen, China.
5. Discounts: We offer discount for big quantity.
1. For all your inquiries about us or our products, we will reply you in detail within 24 hours.
2. Well-trained and professional sales & after- sale services stuff who can speak fluent English.
3. OEM service is available. Can print your own logo on product, customized the retail box packing.
4. With experienced R&D engineers and strong ability to do ODM projects.
