Specifications
round electronic transformer 1. Waterproof IP672. CE, ROHS Approved.
3. Suitable for LED lighting and LED sign applications
SERVICES:
1. If the product specification above is different from what you require actually. Pls kindly inform us in details, we can do the OEM products as per your specification and Customed Design is also available
2. We provide various kinds of different led drivers and power supply, pls visit our website for more information.
3. Welcome to contact me via trademanager or leave me a inquiry mail, I will reply within 24 hours, pls kindly notice the time difference.
round electronic transformer
Features:
·Suitable for LED lighting and LED sign applications |
·Protections: Short circuit / Over Voltage |
·IP67 design for indoor or outdoor installations |
·Efficiency: 80% |
·100% full load burn-in test |
·Storage temperature: -40-80°C |
·Operating temperature: -25-45°C |
·MTBF: Min200Khrs |
·Warranty: One and a half years |
Specifications:
Model |
CV-12010A(new) |
||||
OUTPUT |
DC Voltage |
12±0.5VDC |
|||
Rated power |
10W |
||||
Max current |
0.83A |
||||
INPUT |
Voltage |
90-250VAC |
|||
Frequency |
47 ~ 63 Hz |
||||
AC Current |
0.08A |
||||
Efficiency (Typ.) |
80% |
||||
PROTECTION |
Overload |
20% exceed is allowing |
|||
Short Circuit |
Auto recovery |
||||
Over Voltage |
≤255V |
||||
Over temperature |
≤85°C |
||||
OTHERS |
Cooling |
By convection |
|||
Withstand voltage |
2200VAC |
||||
Dimension/Weight |
58*24mm/135g |
||||
Packing/Carton Size |
100pcs/carton / 37.5*31*16cm |
||||
Cable |
0.75sq.mm. VDE wire 150mm |
||||
Housing Material |
Aluminum |
||||
